Airtac 2JW Angle Seat Valve 2JWY32032Q63G
2. Stainless steel construction of body and linkage rod ensures superior corrosion resistance. PTFE seals provide wide compatibility with high-temperature and highly corrosive fluids.
3. 45° angular seat design with streamlined internal cavity reduces flow path resistance for stabilized fluid flow and achieves high flow rates. Integrated filter element in linkage rod prevents contaminant ingress, extending service life.
4. Actuator equipped with visual position indicator window for real-time valve opening monitoring and flow regulation. Convertible to accommodate limit switches or emergency manual override.
5. Recessed metal fittings on actuator ports with transitional mounting plate ensures simplified integration with NAMUR solenoid valves.
6. 360° rotatable actuator design simplifies installation orientation.
Category: Angular Seat Valves | Brand: AirTAC | Series: 2JW
AirTAC 2JWY32032Q63G Angle Seat Valve Specifications
- Model: 2JWY32032Q63G
- Type: 2/2-way normally closed (spring return)
- Port size: G1" (BSPP thread)
- Actuation: Pneumatic pilot with manual override
- Operating pressure: 0.15–1.0 MPa
- Max working pressure: 10 bar
- Voltage options: DC24V (solenoid version), 0.6W coil power
- Weight: 850g ±3% (without accessories)
- Dimensions: 120mm(L) × 80mm(W) × 105mm(H)
- Body material: Stainless steel CF8M (316 equivalent)
- Seal material: PTFE + FKM compound
- Temperature range: -10℃ to 180℃ (media dependent)
- Response time: ≤0.3s (at 6 bar pressure)
- Flow coefficient (Cv): 4.2
- Protection rating: IP67 (solenoid version)
- Media compatibility: Steam, water, mild chemicals, compressed air
Heavy-duty angle pattern valve with 90° flow path, featuring a stainless steel body with enhanced corrosion resistance. The 45° seat design ensures bubble-tight shut-off (zero leakage Class IV) and low actuation force. Includes a visual position indicator and meets ISO 5211 mounting interface standards. Requires 5μm filtered air supply for pilot operation.
- Steam line control in food processing equipment
- High-temperature liquid dosing systems
- Chemical injection systems in pharmaceutical manufacturing
- Water treatment plant pneumatic controls
- Packaging machine sterilization circuits
Installation note:
Mount with flow direction arrow aligned. For steam applications,
allow 15-minute warm-up with valve partially open to prevent thermal shock.
Maintain 20mm clearance around actuator for heat dissipation.
| Property | Property Value |
|---|---|
| sku | 2JWY32032Q63G |
| Port Size | G1-1/4 |
| Flow Aperture | <32 mm> |
