AirTAC 4V Series · 5/2-way Solenoid Valve

AirTAC 4V210-06 Solenoid Valve, 4V200 Series (4V21006A-W)

The AirTAC 4V210-06 Solenoid Valve, 4V200 Series (4V21006A-W) is a genuine 5/2-way single solenoid (spring return) solenoid valve with PT1/8 ports and an effective area of 17.0 mm² (Cv 1.0). It is an internally piloted spool valve that directs compressed air to double-acting cylinders and actuators.

  • Valve type5/2-way
  • FunctionSingle solenoid (spring return)
  • Port sizePT1/8
  • Effective area17.0 mm²
  • Flow (Cv)1.0
  • Series4V200
$28.65 $33.05Save 13% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every 4V210-06 stroke, mounting and version on one page All 4V210-06 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the AirTAC 4V210-06 Solenoid Valve, 4V200 Series (4V21006A-W)

The 4V21006A-W is the external-pilot (-W) version of AirTAC's 4V200-size 5/2 single-solenoid valve with 1/8in PT ports and an AC220V coil. Instead of feeding the pilot from the main line, a separate external pilot port supplies the switching signal, so the spool still shifts dependably when main-line pressure dips or the circuit runs at very low pressure. With one solenoid and a spring return, the valve directs air to a double-acting cylinder while the solenoid is energised and springs back to the rest position the moment the signal is removed - ideal where the actuator must always return to a known end when the signal drops.

Flow sits in the 4V200 class at 17.0 mm2 effective area (Cv 1.0, catalog figure for the 4V210-08), a good match for double-acting cylinders around O32-50 mm bore. Switching response is 0.05 s or better, the AC220V coil draws 4.5 VA, and the valve weighs 220 g. Air is filtered by a 40 um element, operating pressure spans 0.15-0.8 MPa, and the IP65 terminal-box entry keeps wiring simple in cabinet or on-machine installations.

AirTAC 4V210-06 Solenoid Valve, 4V200 Series (4V21006A-W) Technical Specifications

ModelAirTAC 4V210-06 Solenoid Valve, 4V200 Series (4V21006A-W)
Series4V200 solenoid valve (spool type)
Valve type5/2-way
FunctionSingle solenoid (spring return)
Port sizePT1/8
Exhaust portPT1/8
Effective area (Cv)17.0 mm² (Cv 1.0)
FluidAir (filtered by 40µm element)
Pilot typeInternal / external pilot
Operating pressure0.15 – 0.8 MPa
Proof pressure1.2 MPa
Max frequency5 cycle/sec
Response time≤ 0.05 s (activating)
Temperature-20 to +70 °C
Body materialAluminum alloy
Weight220 g

Specifications follow the official AirTAC 4V series datasheet. Lubrication not required. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.

Flow & Coil Options

Effective area17.0 mm²
Flow coefficientCv 1.0
Response time≤ 0.05 s
Coil powerAC 4.5 VA · DC24V 3.0 W · DC12V 2.5 W
Protection / insulationIP65 (DIN40050), B-class
Voltage optionsDC24V, DC12V, AC110V, AC220V
Manual overrideYes (locking / non-locking)

Size the valve so effective area / Cv is not the bottleneck for your cylinder bore and speed. Undersized valves slow the actuator. Note 5/3 (center) versions have a smaller effective area than the 5/2 of the same body size.

Model Code: AirTAC 4V210-06 Solenoid Valve, 4V200 Series (4V21006A-W)

4VSolenoid valve, spool type, 4-series.
2Body size (4V200) — sets port & flow.
1Function: 1 = single 5/2, 2 = double 5/2, 3 = 5/3.
-06Port thread: M5 / 06=1/8" / 08=1/4" / 10=3/8" / 15=1/2".

Related: 4V210 (single), 4V220 (double), 4V230C/E/P (5/3 center). Add the voltage suffix when ordering.

Where the AirTAC 4V210-06 Solenoid Valve, 4V200 Series (4V21006A-W) Is Used

precision_manufacturing

Low-pressure test and vacuum circuits

External pilot air lets the spool switch even when line pressure is barely above atmospheric, making this valve a fit for leak-test stations, vacuum handling and other low-pressure circuits an internally piloted valve struggles with.

build

Clamps and workholding that must retract

The spring-return 5/2 function drives a double-acting clamp or pusher while energised and automatically returns it when the signal drops - a natural choice for fixtures that must clear the part on every cycle stop.

view_module

Multi-station manifold assemblies

On a shared 4V200 manifold base, several 4V21006A-W valves run pick-and-place or assembly stations in parallel, with the external pilot port keeping every station switching consistently across the group.

Is the AirTAC 4V210-06 Solenoid Valve, 4V200 Series (4V21006A-W) the Right Valve?

Size the flow first: at Cv 1.0 (catalog figure for the 4V210-08) this 4V200 body suits O32-50 mm double-acting bores on moderate cycle rates. Drop to the 4V100 (Cv 0.6) for a small cylinder or slow motion; step up to the 4V300 (Cv 1.65) when you need a bigger bore or a faster stroke. Choose function 10 (this single-solenoid spring return) when the cylinder must return on signal loss, function 20 (double solenoid) when it should remember position, or a 30C/E/P 5/3 when you need hold, float or pressurise at center - note the 5/3 variants flow less (13.6 mm2, Cv 0.8). Mount single valves on the body or assemble a shared manifold base for multi-station circuits.

For a like-for-like replacement match five points: body size 4V200, function digit 10, port and thread (1/8in, PT tapered - G or NPT variants exist), coil voltage (here AC220V, 4.5 VA), and electrical entry (terminal box - grommet versions are listed separately). Confirm the -W external-pilot option is also required, as pilot plumbing differs from the internally piloted standard model.

Quick checklist

  • ✓ Required flow (Cv) for cylinder & speed
  • ✓ Function: single / double / 5-3 center
  • ✓ Coil voltage (DC24 / AC220 …)
  • ✓ Port thread (M5 / 1/8 / 1/4 / 3/8 / 1/2)
  • ✓ Single valve or manifold base?
Ask an Engineer

Installation & Wiring Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 0.8 MPa operating pressure.
  • check Match coil voltage to your controller output.
  • check Use the manual override to test before powering.
  • check Fit silencers or fittings to the exhaust ports.
  • check Wiring by qualified personnel per AirTAC docs.

AirTAC 4V210-06 Solenoid Valve, 4V200 Series (4V21006A-W) FAQ

It is a 5/2 single-solenoid valve for double-acting cylinders and actuators, rated at 17.0 mm2 effective area (Cv 1.0, catalog figure for the 4V210-08), so it suits roughly O32-50 mm bores. The -W suffix means pilot air comes from a separate external port rather than the main line, so switching stays reliable when main-line pressure is low or in vacuum/low-pressure circuits.

One solenoid shifts the spool; energise it (AC220V, 4.5 VA coil) and the valve sends air to the cylinder's working side while venting the other. Cut the signal and an internal spring returns the spool - and the cylinder - to the rest position. If you would rather the valve hold its last pulsed position, that is the double-solenoid 4V220 version instead.
