This model is discontinued

AirTAC has phased out the ACP series. You can still order this code here: we ship the current replacement ACE100X125B, the same code under the new prefix. The ACE replacement is a current-production ISO 21287 compact cylinder in the same bore, stroke and force class, with a matching short body and the same mounting-accessory family, so it fits the same envelope. Confirm mounting-interface dimensions against the ACE datasheet before ordering.

AirTAC ACP Series · Discontinued Compact Cylinder

Airtac ACP Compact Cylinder ACP100X125B

The AirTAC ACP Compact Cylinder ACP100X125B is a double acting DIN-standard tight/compact air cylinder with a Ø100mm bore and 125mm stroke, 1/4" air ports and a hard-anodized aluminium body. This model is discontinued — the current-production replacement is the ACE100X125B (ISO 21287 ACE), in the same bore, stroke and force class.

  • BoreØ100 mm
  • Stroke125 mm
  • Port size1/4"
  • Acting typeDouble acting
  • Rod threadM16×1.5
  • StatusDiscontinued → ACE100X125B
$245.44 $265.69Save 7% Ships as ACE100X125B (current AirTAC replacement)
Ships as ACE100X125B, the current AirTAC replacement (the same code under the new prefix). Order this code as usual. Your cart, checkout and order confirmation will show the ACE100X125B we ship. View ACE100X125B
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every ACP100 stroke, mounting and version on one page All ACP100 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac ACP Compact Cylinder ACP100X125B

The ACP100X125B is a double acting compact cylinder in the DIN-standard ACP series, with a 100 mm bore, 125 mm stroke and a male rod thread (B code). Air drives the piston in both directions, and a fixed TPU bumper sits at each end of travel. At 0.5 MPa it pushes with 3927 N and pulls with 3681.6 N; at 0.7 MPa push rises to 5497.8 N, with a theoretical peak of 800.9 kgf at 1.0 MPa. The hard-anodized aluminium body and S45C hard-chrome rod run on 0.15-1.0 MPa (22-145 psi) at 30-500 mm/s.

Its short ISO 21287-class body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so it slots into heavy presses, clamping fixtures and gantries where a full-length body will not fit. Note this model is discontinued: the current-production direct is ACE100X125, same bore, stroke and force class - confirm the ISO 21287 mounting dimensions before swapping.

Airtac ACP Compact Cylinder ACP100X125B Technical Specifications

ModelAirtac ACP Compact Cylinder ACP100X125B
SeriesACP DIN compact cylinder (discontinued)
ReplacementACE100X125B
Bore sizeØ100 mm
Stroke125 mm
Acting typeDouble acting
Port size1/4"
Rod threadM16×1.5
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed bumper (both ends)
Max standard strokeUp to 300 mm

Specifications follow the official AirTAC ACP datasheet (now discontinued). The ACE100X125B (ISO 21287) carries the same bore/stroke/force class; confirm mounting-interface dimensions against the ACE datasheet before installation. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G.

Theoretical Output Force (Ø100mm)

PressurePush forcePull force
0.5 MPa3927 N3682 N
0.7 MPa5498 N5154 N
Max (@1.0 MPa)801 kgf

The ACE100X125B produces the same force from the same bore. Actual usable force is lower than theoretical; size with a margin.

Model Code: Airtac ACP Compact Cylinder ACP100X125B

ACPDIN compact cylinder (double-acting, discontinued).
100Bore size in mm.
×125Stroke length in mm.
SOptional built-in magnet for sensor position sensing (omit for no magnet).
BRod type: B = male thread; blank = female thread.

Replacement mapping (swap P for E): ACP→ACE, ASP→ASE, ATP→ATE, ACPD→ACED, ACPJ→ACEJ. ACP-family: ACP (double acting), ASP / ATP (single acting push / pull), ACPD (double rod), ACPJ (double rod, adjustable stroke).

Where the Airtac ACP Compact Cylinder ACP100X125B Is Used

compress

Heavy press and forming stations

With 3927 N push at 0.5 MPa (about 5498 N at 0.7 MPa), the 100 mm bore handles stamping, crimping and press-fit operations on sheet-metal assemblies where a 125 mm stroke covers the part-to-tool gap.

factory

Automotive fixture clamping

The short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, letting the ACP100X125B clamp weld fixtures and machining jigs inside tight guards; roughly 2356 N of usable force secures steel brackets without over-clamping.

Replacing the Airtac ACP Compact Cylinder ACP100X125B with the ACE100X125B

At 100 mm bore this is the top of the ACP range: 3927 N push at 0.5 MPa versus 2513 N for an 80 mm bore, so step down only if your load is under about 2500 N. The 125 mm stroke sits well inside the 300 mm max standard stroke for this bore, so it is a catalogue item, not a made-to-order length. The B code gives a male rod thread on a 25 mm rod with a 1/4" PT port. Mounting brackets (FA/FB flange, LB foot, CA/CB clevis and related hardware) bolt to the standard face; order the -S code if you need the optional magnet for CMSE / DMSE switches - without it there is no magnet. A plain cylinder drifts when air is lost, so add a rod lock or pilot check valve for held loads. Order ACE100X125 as the current replacement.

Replacement checklist

  • ✓ Current-production ACE → ACE100X125B
  • ✓ Same bore / stroke / force class
  • ✓ Confirm ISO 21287 mounting dimensions
  • ✓ Port/thread type (PT / G)
  • ✓ Add -S for magnet if you need sensors
View ACE100X125B

Airtac ACP Compact Cylinder ACP100X125B FAQ

At 0.5 MPa the double-acting piston delivers 3927 N push and 3681.6 N pull; at 0.7 MPa push reaches 5497.8 N, and the theoretical maximum is 800.9 kgf at 1.0 MPa. Operating range is 0.15-1.0 MPa (22-145 psi) at 30-500 mm/s. The ACP100X125B is discontinued; the current-production direct is ACE100X125 in the same bore, stroke and force class - confirm the ISO 21287 mounting dimensions before ordering.

The 100 mm bore body is a compact ISO 21287-class design in hard-anodized aluminium with an S45C hard-chrome 25 mm rod, saving about 50% of the mounting length of an ISO 15552 profile cylinder. The B code specifies a male rod thread; the air port is 1/4" PT. FA/FB flange, LB foot and CA/CB clevis hardware bolt to the standard face, and the optional -S magnet enables CMSE / DMSE switches - this model without -S carries no magnet. A fixed TPU bumper at each end only decelerates the piston; it never locks a load.
