Airtac ACP Compact Cylinder ACP100X125SB
2. Enhanced structural integrity with threaded end covers for superior strength and maintenance accessibility;
3. Barrel interior features precision machining with hard anodized treatment for exceptional wear resistance and durability;
4. Specialized bidirectional sealing structure on piston ensures compact dimensions with integrated oil reservoir functionality;
5. Space-optimized compact design for efficient spatial utilization in installations;
6. Perimeter grooves for magnetic sensor switch mounting with tool-free installation convenience;
7. Multiple mounting accessory configurations available for flexible adaptation;
Category: Compact Cylinders | Brand: AirTAC | Series: ACP
AirTAC ACP Compact Cylinder ACP100X125SB Technical Details
- Model: ACP100X125SB
- Type: Single-acting spring return compact cylinder
- Bore size: Ø100mm
- Stroke: 125mm (±0.5mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Cushion type: Adjustable pneumatic cushion
- Port size: G3/8 (NPT1/2 optional)
- Piston rod thread: M20×1.5
- Mounting style: Basic type (MF1) with front flange
- Seal material: NBR + special wear-resistant coating
- Temperature range: -10℃ to 80℃
- Protection rating: IP40 (dust protected)
- Weight: 3.8kg (without accessories)
- Dimensions: 325mm(L) × 160mm(W) × 160mm(H)
(Stroke length included, base mounting plate: 200×200×20mm)
High-rigidity compact cylinder with reduced mounting dimensions (30% smaller than standard series). Features anti-corrosion hard aluminum alloy tube and chromium-plated piston rod with integrated scrape ring. Optimal for high cycle rates (up to 3 cycles/sec) with built-in auto-lubrication design. Requires 5μm filtered air supply with ISO 8573-1:2010 Class 3 air quality.
- Precision clamping in PCB assembly lines
- Vertical lifting mechanisms in food packaging
- Door actuation systems for automotive welding robots
- Positioning stages in medical device manufacturing
- Material ejection in injection molding machines
Installation guidance:
Mount using Class 8.8 or higher grade fasteners. Lubricate through air supply (ISO VG32 recommended).
Allow 15mm clearance around cylinder body for heat dissipation during continuous operation.
| Property | Property Value |
|---|---|
| sku | ACP100X125SB |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/4" Thread |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 125mm |
