This model is discontinued
AirTAC has phased out the ACP series. You can still order this code here: we ship the current replacement ACEJ12X100-75S, the same code under the new prefix. The ACE replacement is a current-production ISO 21287 compact cylinder in the same bore, stroke and force class, with a matching short body and the same mounting-accessory family, so it fits the same envelope. Confirm mounting-interface dimensions against the ACE datasheet before ordering.
Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-75S
The AirTAC ACPJ Adjustable Compact Cylinder ACPJ12X100-75S is a double acting, double rod, adjustable stroke DIN-standard tight/compact air cylinder with a Ø12mm bore and 100mm stroke, M5×0.8 air ports and a hard-anodized aluminium body. This model is discontinued — the current-production replacement is the ACEJ12X100-75S (ISO 21287 ACE), in the same bore, stroke and force class.
- BoreØ12 mm
- Stroke100 mm
- Port sizeM5×0.8
- Acting typeDouble acting, double rod, adjustable stroke
- Rod threadM3×0.5
- StatusDiscontinued → ACEJ12X100-75S
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-75S
Double acting and adjustable in stroke, the ACPJ12X100-75S is a discontinued DIN-standard compact cylinder with a 12 mm bore and a 100 mm stroke that a stop screw can trim by up to 75 mm, giving a usable extend range of 25-100 mm. At 0.5 MPa it pushes 56.5 N and pulls 42.4 N, rising to 79.2 N / 59.4 N at 0.7 MPa. Because the short ISO 21287-class body saves about 50% of the mounting length of an ISO 15552 profile cylinder, it slots into tight fixtures and guarding where a full-length body cannot. The 100 mm stroke exceeds the 50 mm standard maximum for this bore, so it is a made-to-order item.
A practical sizing check: treat roughly 0.6 of the 56.5 N push as usable work at 0.5 MPa, about 34 N, which is roughly 3 kg of vertical lift with a margin - enough for small clamps, gates and sensors trays. The hard-anodized aluminium body carries a fixed TPU bumper at both ends, the S45C rod ends in a female M3x0.5 thread, and the fitted -S magnet accepts CMSE / DMSE switches. This model is discontinued; the current-production drop-in is the ACEJ12X100, so confirm ISO 21287 mounting dimensions before swapping.
Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-75S Technical Specifications
| Model | Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-75S |
|---|---|
| Series | ACPJ DIN compact cylinder (discontinued) |
| Replacement | ACEJ12X100-75S |
| Bore size | Ø12 mm |
| Stroke | 100 mm |
| Acting type | Double acting, double rod, adjustable stroke |
| Port size | M5×0.8 |
| Rod thread | M3×0.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed bumper (both ends) |
| Max standard stroke | Up to 50 mm |
Specifications follow the official AirTAC ACP datasheet (now discontinued). The ACEJ12X100-75S (ISO 21287) carries the same bore/stroke/force class; confirm mounting-interface dimensions against the ACE datasheet before installation. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G.
Theoretical Output Force (Ø12mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 42 N |
| 0.7 MPa | 59 N |
| Max (@1.0 MPa) | 9 kgf |
ACPJ is double-rod: the rear rod that carries the stroke adjuster exits the rear cover, so both piston faces lose rod area. The rod-side (annular) area is used for both directions (conservative).
Model Code: Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-75S
| ACPJ | DIN compact cylinder (adjustable-stroke, discontinued). |
|---|---|
| 12 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -75 | Adjustable stroke window (mm the extend stroke can be shortened on site). |
| S | Optional built-in magnet for sensor position sensing (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
Replacement mapping (swap P for E): ACP→ACE, ASP→ASE, ATP→ATE, ACPD→ACED, ACPJ→ACEJ. ACP-family: ACP (double acting), ASP / ATP (single acting push / pull), ACPD (double rod), ACPJ (double rod, adjustable stroke).
Where the Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-75S Is Used
Small-part ejection on assembly benches
The 25-100 mm adjustable extend range lets one cylinder serve several fixture variants, nudging finished 3-5 g parts off a jig at about 3 kg of usable vertical force at 0.5 MPa.
Position-confirmed slide gates in test rigs
With the fitted -S magnet and CMSE / DMSE switches, both end positions of the trimmed stroke are confirmed electrically, ideal for interlocked covers on electronics test stations.
Light hold-down of PCBs in solder pallets
About 34 N of practical push at 0.5 MPa holds thin circuit boards flat during wave-solder transfer, and the short body fits inside the pallet frame where longer bodies cannot.
Replacing the Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-75S with the ACEJ12X100-75S
At 56.5 N push at 0.5 MPa this 12 mm bore suits light clamping and positioning; step up to the 16 mm bore (100.5 N) or the 20 mm bore (157.1 N) if the load grows. Remember the stop screw trims the extend stroke only - it is not a mid-stroke lock, so the rod still drifts if air is lost. The 75 mm window covers jobs needing anywhere from 25 mm to the full 100 mm. FA/FB flange and LB foot mountings bolt to the standard face, and the fitted -S magnet lets you add CMSE / DMSE switches for end-position sensing. Order the ACEJ12X100 instead: this ACPJ is discontinued, and the ACE matches the same bore, stroke and force class.
Replacement checklist
- ✓ Current-production ACE → ACEJ12X100-75S
- ✓ Same bore / stroke / force class
- ✓ Confirm ISO 21287 mounting dimensions
- ✓ Port/thread type (PT / G)
- ✓ Add -S for magnet if you need sensors
Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-75S FAQ
At 0.5 MPa it pushes 56.5 N and pulls 42.4 N; at 0.7 MPa those rise to 79.2 N and 59.4 N, with a theoretical maximum of 11.5 kgf at 1.0 MPa. The -75 code gives a 75 mm adjustment window, so the stop screw trims the 100 mm extend stroke anywhere down to 25 mm. The 100 mm stroke is a made-to-order length because the standard maximum for a 12 mm bore is 50 mm. Operating pressure is 0.15-1.0 MPa (22-145 psi) and speed is 30-500 mm/s.
It is a compact short-body cylinder with a hard-anodized aluminium body, an S45C hard-chrome rod with a female M3x0.5 thread, an M5x0.8 port and a fixed TPU bumper at each end - the body is roughly 50% shorter in mounting length than an ISO 15552 profile cylinder. The -S magnet fitted to this model accepts CMSE / DMSE switches. The ACPJ family is discontinued; the current-production drop-in is the ACEJ12X100 in the same bore, stroke and force class - confirm the ISO 21287 mounting dimensions before you swap.
