AirTAC ACQJ Series · JIS Compact Adjustable-Stroke Cylinder

Airtac Adjustable Compact Cylinder ACQJ50~63 ACQJ50X100-100B

The AirTAC Adjustable Compact Cylinder ACQJ50~63 ACQJ50X100-100B is a genuine double-acting COMPACT (JIS) cylinder with an EXTERNAL adjustable stop on the extend stroke — a Ø50mm bore and 100mm full stroke. Turn the stop to fine-tune the end position on the machine without changing parts.

  • BoreØ50 mm
  • Full stroke100 mm
  • Port sizePT1/4
  • Adjuster threadM16×1.5
$82.31 $89.81Save 8% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every ACQJ50 stroke, mounting and version on one page All ACQJ50 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac Adjustable Compact Cylinder ACQJ50~63 ACQJ50X100-100B

The AirTAC ACQJ50X100-100B is a double-acting JIS compact cylinder with a 50mm bore and 100mm full stroke. An external threaded stop and lock nut restrict the extend end position, providing a usable forward range of 0-100mm. The retract stroke remains completely unaffected by this adjustment.

This variant includes a male M18x1.5 rod-end thread for direct load coupling and uses a PT1/4 port. It relies on fixed NBR elastomer bumpers at each end rather than adjustable air cushions. The body features integrated magnetic-switch grooves, though this specific SKU ships without a piston magnet. Operating pressure spans 0.15-1.0MPa, with a proof pressure of 1.5MPa.

Airtac Adjustable Compact Cylinder ACQJ50~63 ACQJ50X100-100B Technical Specifications

ModelAirtac Adjustable Compact Cylinder ACQJ50~63 ACQJ50X100-100B
SeriesACQJ JIS compact adjustable-stroke cylinder
Bore sizeØ50 mm
Full stroke100 mm
Adjuster threadM16×1.5
Port sizePT1/4
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
Rod threadM10×1.5 (F) / M18×1.5 (B)

Specifications follow the official AirTAC ACQJ datasheet. The adjustable stop shortens the EXTEND stroke only; ACQJ is double-rod, so push is lower than a standard ACQ of this bore. Adjustable window options: 10/20/30/40/50/75/100 mm.

Theoretical Output Force (Ø50mm)

PressurePush forcePull force
0.5 MPa825 N825 N
0.7 MPa1155 N—
Max (@1.0 MPa)168 kgf

ACQJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod ACQ push of the same bore. Actual usable force is lower due to friction; size with a safety margin.

Model Code: Airtac Adjustable Compact Cylinder ACQJ50~63 ACQJ50X100-100B

ACQJJIS compact double-acting ADJUSTABLE-STROKE cylinder series.
50Bore size in mm.
×100Full stroke length in mm.
-0Adjustable window in mm (extend stroke can be shortened by up to this).
S / BMagnet (S) / male-thread rod (B); omit for none / female thread.

Thread: PT standard (G / NPT available). Related: ACQ (fixed stroke), ACQD (double rod), TACQ (guided / non-rotating).
