Airtac CLA Standard Solenoid Coil CLA092B
Category: Solenoid Valve Coils | Brand: AIRTAC | Series: CLA
AirTAC CLA Series Solenoid Coil CLA092B Technical Details
- Model: CLA092B (Standard Duty Coil)
- Valve compatibility: Designed for 4V/5V/EV series valves
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 5W (AC), 4.5W (DC)
- Insulation class: Class F (155℃)
- Temperature range: -20℃ to +50℃ (no icing)
- Protection rating: IP65 (dust-tight & water jet resistant)
- Inductance: 0.8H ±10% (DC24V model)
- Coil resistance: 115Ω ±10% (DC24V version)
- Enclosure material: UL94 V-0 rated PBT plastic
- Winding material: Class 180 enameled copper wire
- Lead wire: 22AWG PVC cable, 200mm length
- Weight: 210g ±5%
- Dimensions: 50mm (L) × 30mm (W) × 40mm (H)
Universal replacement coil with dual-voltage compatibility, featuring overcurrent protection design and vibration-resistant construction. The encapsulated winding structure prevents moisture ingress while maintaining thermal dissipation efficiency. Certified for continuous duty cycle operation with 100,000+ mechanical life cycles.
- Automated assembly line valve actuators
- Plastic injection molding machine controls
- CNC tool changer pneumatic systems
- Food processing equipment valves
- Semiconductor manufacturing gas control
Installation guidelines:
Ensure coil voltage matches control system specifications. Maintain 15mm clearance from heat sources.
Use M4 mounting screws with 0.4-0.6Nm torque. Apply dielectric grease on connector pins in humid environments.
| Property | Property Value |
|---|---|
| sku | CLA092B |
| Standard Voltage | DC24V |
| Coil Inner Diameter | 9.0mm |
