Airtac CLA Standard Solenoid Coil CLA092C
$9.27
Regular price
$16.77
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
CLA092C
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The solenoid coil operates on the principle of electromagnetic induction, where a magnetic field is generated around a current-carrying conductor. By winding the conductor into a tightly coiled helical configuration, the magnetic flux density is amplified, achieving optimal field intensity within minimal spatial constraints. The implementation of enamel-insulated windings (as opposed to standard conductors) ensures compact design while maintaining electrical isolation.
Category: Solenoid Valve Coils | Brand: AIRTAC | Series: CLA
Operational guidance:
Maintain ambient temperature below 50℃ with minimum 15mm clearance from adjacent components.
Use torque wrench for installation to prevent core tube deformation.
Not compatible with PWM controllers exceeding 10kHz frequency.
Category: Solenoid Valve Coils | Brand: AIRTAC | Series: CLA
AirTAC CLA092C Standard Coil Technical Details
- Model: CLA092C (Standard Coil Series)
- Valve compatibility: Designed for 4V/5V/HE series valves
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (±10% 50/60Hz), AC220V (±10% 50/60Hz)
- Power consumption: 3.8W (DC), 4.5VA (AC)
- Insulation class: Class B (130℃)
- Duty cycle: 100% ED (Continuous operation capable)
- Coil resistance: 75Ω ±10% (DC24V model)
- Temperature range: -20℃ to +50℃ (No freezing)
- Protection rating: IP65 (Dust-tight & water jet resistant)
- Lead wire: 300mm length, 22 AWG PVC insulated
- Connector type: DIN43650 Form A compatible
- Core tube material: Stainless steel SUS304
- Weight: 220g ±5% (Excluding connector)
- Dimensions: 42mm(W) × 38mm(D) × 48mm(H)
- Mounting torque: 0.5-0.7N·m (For secure valve attachment)
High-efficiency solenoid coil with overcurrent protection design, featuring anti-vibration construction for industrial environments. The epoxy-encapsulated winding ensures moisture resistance and thermal stability. Compatible with ISO 4400 standard mounting interfaces.
Application Scenarios:
- Automated production line valve clusters
- Plastic injection molding machine controls
- Food processing pneumatic systems (Washdown environments)
- Semiconductor manufacturing equipment
- Elevator brake safety circuits
Operational guidance:
Maintain ambient temperature below 50℃ with minimum 15mm clearance from adjacent components.
Use torque wrench for installation to prevent core tube deformation.
Not compatible with PWM controllers exceeding 10kHz frequency.
Electrical connections:
Red lead - Positive (DC)/Phase (AC), Blue lead - Negative (DC)/Neutral (AC).
Always install with surge absorber (e.g., R-C network) when controlling inductive loads.
