Airtac HFSZ Guided Parallel Pneumatic Gripper HFSZ10
1. Integrated linear guide design delivers exceptional rigidity and precision for stable operation;
2. Equipped with positioning dowel pins at guide base to prevent guideway-body misalignment;
3. Deepened reference centering holes on body enhance mounting accuracy and ensure consistent repositioning after repeated disassembly;
4. Customizable initial clamping position configuration available to meet diverse application scenarios.
Category: Parallel Pneumatic Grippers | Brand: AirTAC | Series: HFSZ
AirTAC HFSZ10 Guided Parallel Pneumatic Gripper Specifications
- Model: HFSZ10
- Type: Guided parallel type with linear guide rails
- Gripping force: 12-40N (adjustable via air pressure)
- Stroke per jaw: 0-5mm (standard), customizable up to 10mm
- Operating pressure: 0.2-0.7 MPa
- Temperature range: -10℃ to 80℃
- Material: Anodized aluminum body, CRMo steel guide rails
- Guide rail type: Dual linear ball bearing system
- Repeat accuracy: ±0.02mm
- Port size: M5x0.8 (dual ports for push/pull operation)
- Speed adjustment: Built-in flow control valves (0-5 L/min)
- Mounting: Standard ISO 9409-1 pattern with 20mm spacing
- Weight: 450g ±2%
- Dimensions: 100mm(L) × 40mm(W) × 30mm(H)
- Seal material: Heat-resistant NBR+PU hybrid seals
- Shock resistance: 15G acceleration (10ms duration)
Precision parallel gripper featuring hardened linear guides for zero-backlash operation. The dual-cylinder design provides symmetrical force distribution, with anti-vibration pads for high-speed applications (up to 3 cycles/sec). Includes magnetic sensor slots for position feedback integration.
- PCB component insertion machines
- Pharmaceutical blister packaging lines
- Automotive fuel injector assembly
- Optical lens handling systems
- Battery cell stacking robots
Operation tip:
For delicate objects, use 0.3-0.4MPa pressure with speed regulators
set to 60% open position. Lubricate guide rails every 500,000 cycles
using ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | HFSZ10 |
| Gripper Optional Types | Standard Type |
| Port Size | M3×0.5 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <10mm> |
| Stroke | <4mm> |
