Airtac HFSZ Guided Parallel Pneumatic Gripper HFSZ20
1. Integrated linear guide design delivers exceptional rigidity and precision for stable operation;
2. Equipped with positioning dowel pins at guide base to prevent guideway-body misalignment;
3. Deepened reference centering holes on body enhance mounting accuracy and ensure consistent repositioning after repeated disassembly;
4. Customizable initial clamping position configuration available to meet diverse application scenarios.
Category: Parallel Pneumatic Grippers | Brand: AirTAC | Series: HFSZ
AirTAC HFSZ20 Rail-Guided Parallel Pneumatic Gripper Specifications
- Model: HFSZ20
- Type: Rail-guided parallel movement (dual-piston design)
- Guide rail type: T-slot linear guide system
- Gripping force: 200N at 0.6MPa
- Stroke per jaw: 0-20mm (adjustable)
- Operating pressure: 0.2-0.7 MPa
- Port size: M5 (1/8")
- Repeat accuracy: ±0.03mm
- Material: Aluminum alloy body, polyurethane seals
- Temperature range: -10℃ to 80℃
- Protection rating: IP54
- Mounting hole pattern: 32mm x 32mm (M4x0.7 threaded)
- Air consumption: 18.5cm³/stroke
- Max cycling speed: 200mm/s
- Endurance: 50 million cycles
- Weight: 480g ±5%
- Dimensions: 100mm(L) × 42mm(W) × 34mm(H)
Precision rail-guided gripper with T-slot mechanism for ultra-stable linear motion. Features anti-rotation design for parallel jaw movement and built-in shock absorption pads. Requires 5-40μm filtered lubricated air (ISO 8573-1). Compatible with vacuum cups and custom tooling via M3 mounting threads on jaws.
- PCB component insertion in electronics assembly
- Precision part transfer in watch manufacturing
- Battery cell handling in EV production lines
- Medical device positioning for laser marking
- Glass panel gripping for display panel installations
Operation tip:
Maintain 0.5-1mm clearance between jaws and workpiece during initial setup.
Lubricate guide rails every 500,000 cycles using ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | HFSZ20 |
| Gripper Optional Types | Standard Type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <20mm> |
| Stroke | <10mm> |
