Airtac HFSZ Guided Parallel Pneumatic Gripper HFSZ32
1. Integrated linear guide design delivers exceptional rigidity and precision for stable operation;
2. Equipped with positioning dowel pins at guide base to prevent guideway-body misalignment;
3. Deepened reference centering holes on body enhance mounting accuracy and ensure consistent repositioning after repeated disassembly;
4. Customizable initial clamping position configuration available to meet diverse application scenarios.
Category: Parallel Pneumatic Grippers | Brand: AirTAC | Series: HFSZ
AirTAC HFSZ32 Rail-Guided Parallel Pneumatic Gripper Specifications
- Model: HFSZ32
- Type: Double-acting rail-guided parallel gripper
- Gripping force: 18-230N (adjustable via air pressure)
- Stroke per jaw: 0-10mm (standard), customizable up to 20mm
- Operating pressure: 0.2-0.7 MPa
- Port size: M5 x 0.8 (dual ports for simultaneous actuation)
- Guide mechanism: Dual linear ball bearings with preload adjustment
- Weight: 485g ±5g (including rail system)
- Dimensions: 150mm(L) × 60mm(W) × 40mm(H)
- Main body material: Anodized aluminum alloy (A6063-T5)
- Jaw material: Steel quenched to HRC45-50
- Operating temperature: -10℃ to 80℃
- Repeat accuracy: ±0.02mm
- Maximum speed: 100mm/s (at 0.5MPa)
- Protection rating: IP54 (standard), IP67 optional
- Mounting: 4x M4 threaded holes (8mm depth)
Precision parallel gripper with integrated linear guides, featuring zero backlash operation and wear compensation. The hardened steel jaws and chromium-plated shafts ensure durability in high-cycle applications (up to 10 million cycles). Includes built-in shock absorbers for smooth gripping at maximum speed.
- PCB component insertion machines
- Automotive engine part assembly lines
- Pharmaceutical blister packaging systems
- Robotic pick-and-place for fragile items (glass panels, SMD components)
- Precision machining fixture automation
Operation tip:
For optimal performance, use ISO 8573-1 class 3 lubricated air (1-2 drops of ISO VG32 oil per m³).
Maintain 0.3mm minimum clearance between jaws during homing position to prevent over-compression.
- Custom jaw stroke (requires factory calibration)
- High-temperature variant (up to 120℃)
- Magnetic sensor ready (slot for M5 proximity switches)
- Anti-vibration mounting brackets available
| Property | Property Value |
|---|---|
| sku | HFSZ32 |
| Gripper Optional Types | Standard Type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <32 mm> |
| Stroke | 22mm |
