Airtac HFSZ Guided Parallel Pneumatic Gripper HFSZ6
1. Integrated linear guide design delivers exceptional rigidity and precision for stable operation;
2. Equipped with positioning dowel pins at guide base to prevent guideway-body misalignment;
3. Deepened reference centering holes on body enhance mounting accuracy and ensure consistent repositioning after repeated disassembly;
4. Customizable initial clamping position configuration available to meet diverse application scenarios.
Category: Parallel Pneumatic Grippers | Brand: AirTAC | Series: HFSZ
AirTAC HFSZ6 Guided Parallel Pneumatic Gripper Specifications
- Model: HFSZ6
- Type: Guided parallel gripper (dual rail structure)
- Bore size: Ø6mm
- Operating pressure: 0.1-0.7 MPa (14.5-101.5 PSI)
- Stroke per jaw: 2-5mm (adjustable)
- Gripping force: 4.5-31.5N (pressure-dependent)
- Rail type: Dual linear guide with ball bearings
- Repeat accuracy: ±0.02mm
- Port size: M5x0.8
- Weight: Approx. 180g
- Dimensions: 56mm(L) × 32mm(W) × 24mm(H)
- Piston material: Hard-anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Temperature range: -10℃ to 80℃
- Air consumption: 1.5cm³/stroke
- Response time: 0.1s (at 0.5MPa)
- Mounting pattern: 16mm spacing, M3 threaded holes
Precision parallel gripper with anti-rotation dual guide rails, featuring adjustable stroke and pressure-sensitive gripping force control. The hardened steel rails and preloaded ball bearings ensure smooth operation with minimal play, ideal for delicate part handling. Includes replaceable polyurethane jaw pads with diamond pattern grip surface.
- PCB component insertion machines
- Micro motor shaft handling
- Watch component assembly lines
- Pharmaceutical blister packaging
- Optical lens positioning systems
- 3C product testing equipment
Operation note:
For precision applications, maintain 0.3-0.5MPa operating pressure and
install 5μm filter regulator. Lubricate guide rails monthly with ISO VG32
pneumatic oil. Avoid side-load exceeding 2N during gripping operations.
| Property | Property Value |
|---|---|
| sku | HFSZ6 |
| Gripper Optional Types | Standard Type |
| Port Size | M3×0.5 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <6mm> |
| Stroke | <3mm> |
