Airtac HFSZ Guided Parallel Pneumatic Gripper HFSZ6N
1. Integrated linear guide design delivers exceptional rigidity and precision for stable operation;
2. Equipped with positioning dowel pins at guide base to prevent guideway-body misalignment;
3. Deepened reference centering holes on body enhance mounting accuracy and ensure consistent repositioning after repeated disassembly;
4. Customizable initial clamping position configuration available to meet diverse application scenarios.
Category: Parallel Pneumatic Grippers | Brand: AirTAC | Series: HFSZ
AirTAC HFSZ6N Rail-Guided Parallel Pneumatic Gripper Specifications
- Model: HFSZ6N
- Type: Rail-guided parallel gripper (double-acting)
- Bore size: 6mm
- Operating pressure: 0.1-0.7 MPa
- Max gripping force: 14.1N @ 0.5MPa
- Stroke per jaw: 4mm (standard), customizable up to 12mm
- Repeat accuracy: ±0.02mm
- Guide rail type: Dual linear ball bearings
- Port size: M5x0.8 (standard), NPT1/8 optional
- Weight: 210g (excluding accessories)
- Dimensions: 76mm(L) × 32mm(W) × 25mm(H)
- Body material: Anodized aluminum alloy
- Rail material: Stainless steel
- Seal material: Heat-resistant NBR (-10℃ to 100℃)
- Mounting: 2x M4 threaded holes on base
- Max sliding speed: 500mm/s
- Lubrication: Pre-lubricated (maintenance-free for 5,000km travel)
Precision rail-guided gripper featuring zero-backlash operation and anti-rotation mechanism. The dual linear ball bearing system ensures smooth motion and high positional repeatability, while the hardened steel rails provide exceptional wear resistance. Ideal for high-speed pick-and-place operations requiring micron-level precision.
- PCB component insertion machines
- Watch movement assembly systems
- Pharmaceutical blister packaging lines
- Optical lens handling in camera modules
- Micro-drive mechanism assembly
Operational note:
For optimal performance, maintain air supply dew point ≤3℃ below ambient temperature.
Use 5-10μm filtration and apply 1-2 drops of ISO VG32 turbine oil monthly for heavy-duty cycles.
- HFTF6 series tandem gripper brackets
- HFM6 magnetic sensor kits
- HFSF6 soft jaw adapters
- HFJ6 series vacuum cup conversion kits
| Property | Property Value |
|---|---|
| sku | HFSZ6N |
| Gripper Optional Types | Through-hole mounting type |
| Port Size | M3×0.5 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <6mm> |
| Stroke | <3mm> |
