Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-10
The AirTAC JSIJ32~50 Adjustable Cylinder JSIJ32X100-10 is a genuine double acting, double rod, adjustable stroke JIS-standard air cylinder with a Ø32mm bore and 100mm stroke, G1/8 air ports and adjustable end cushioning. Its no-tie-rod, hard-anodized profile barrel is more compact than an ISO 15552 cylinder of the same bore — a space-saver on tight machines.
- BoreØ32 mm
- Stroke100 mm
- Port sizeG1/8
- Acting typeDouble acting, double rod, adjustable stroke
- Rod threadM10×1.25
- CushionAdjustable, 20 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-10
Its external adjuster shortens the extend stroke by up to 10 mm, yielding a usable 90-100 mm window while the retract end stays fixed. This built-in flexibility means you can fine-tune the stroke without swapping the cylinder. The hard-anodized aluminum profile barrel keeps the total length shorter than a same-bore ISO 15552 unit.
The G1/8 port and adjustable 20 mm air cushions at both ends ensure smooth deceleration. Note that this plain SKU lacks a magnet and cannot take CMSE or DMSE sensors; adding the -S variant enables switch readiness. Furthermore, the cushion only decelerates the piston, so fit an external rod lock or pilot-operated check valve if you need to hold a load on air loss.
Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-10 Technical Specifications
| Model | Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-10 |
|---|---|
| Series | JSI JIS-standard profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 100 mm |
| Acting type | Double acting, double rod, adjustable stroke |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 20 mm |
| Max standard stroke | Up to 1000 mm |
Specifications follow the official AirTAC JSI (JIS standard) datasheet. Confirm against the product label before installation. Thread options: PT (blank) / G. Barrel: hard-anodized aluminum profile (no tie rods).
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | 484 N |
| Max (@1.0 MPa) | 70 kgf | |
JSIJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative).
Model Code: Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-10
| JSIJ | JIS-standard profile cylinder (adjustable-stroke type). |
|---|---|
| 32 | Bore size in mm (32 / 40 / 50 / 63 / 80 / 100 / 125). |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensors. |
JSI-family variants: JSI (double acting), JSID (double rod), JSIJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / TCM1 / TCM2. Thread PT (blank) / G.
Where the Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-10 Is Used
Clamp Position Trimming
Dial in the exact 90 to 100 mm clamping reach on a machining fixture using the external stop screw without replacing the actuator.
Small Part Ejection
Fine-tune the ejection stroke on a 32 mm bore assembly line to accommodate varying product heights while maintaining smooth cushioning.
Transfer Stopper Tuning
Adjust the extend stop on a conveyor diverter by up to 10 mm to perfectly halt different carton sizes on the fly.
Is the Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-10 the Right Cylinder?
The adjustable 10 mm extend window is ideal for sharing a single spare across multiple stroke variants or dialing in a final end position on-site. You can mount it via Basic, FA, LB, TC, TCM1, or TCM2 brackets. Because this specific SKU lacks the -S magnet, it cannot support position sensing. For any stroke at or over 300 mm, always use a guide rail to prevent side-load damage to the rod.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Set cushions to minimum, then release gradually.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-10 FAQ
This 32 mm bore actuator pushes 402 N and pulls 345 N at 0.5 MPa, and pushes 563 N while pulling 483 N at 0.7 MPa. The theoretical maximum force is 82 kgf at 1.0 MPa. It uses a G1/8 air port and features a 12 mm rod with an M10x1.25 thread.
The external adjuster lets you shorten the extend stroke by up to 10 mm on-site, giving a usable extend range of 90 to 100 mm. The nominal 100 mm stroke is the maximum, and the retract end remains fixed. This stop sets the end position but does not lock the load.
