Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-100
The AirTAC JSIJ32~50 Adjustable Cylinder JSIJ32X100-100 is a genuine double acting, double rod, adjustable stroke JIS-standard air cylinder with a Ø32mm bore and 100mm stroke, G1/8 air ports and adjustable end cushioning. Its no-tie-rod, hard-anodized profile barrel is more compact than an ISO 15552 cylinder of the same bore — a space-saver on tight machines.
- BoreØ32 mm
- Stroke100 mm
- Port sizeG1/8
- Acting typeDouble acting, double rod, adjustable stroke
- Rod threadM10×1.25
- CushionAdjustable, 20 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-100
The external adjuster lets you fine-tune the extend end position without swapping the cylinder, so the usable extend stroke becomes 0 to 100 mm while the retract end stays fixed. The hard-anodized aluminum extruded barrel omits tie rods entirely, making the body shorter and more compact than an ISO 15552 cylinder of the same bore.
Because this specific SKU lacks the -S magnet suffix, it cannot accept CMSE or DMSE sensors for position detection. Air connects via a G1/8 port, and adjustable air cushions of 20 mm at both ends absorb impact. Note that the cushion only decelerates the piston; a plain cylinder does not hold load on air loss, so fit an external rod lock or pilot-operated check valve if you need to prevent drift.
Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-100 Technical Specifications
| Model | Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-100 |
|---|---|
| Series | JSI JIS-standard profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 100 mm |
| Acting type | Double acting, double rod, adjustable stroke |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 20 mm |
| Max standard stroke | Up to 1000 mm |
Specifications follow the official AirTAC JSI (JIS standard) datasheet. Confirm against the product label before installation. Thread options: PT (blank) / G. Barrel: hard-anodized aluminum profile (no tie rods).
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | 484 N |
| Max (@1.0 MPa) | 70 kgf | |
JSIJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative).
Model Code: Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-100
| JSIJ | JIS-standard profile cylinder (adjustable-stroke type). |
|---|---|
| 32 | Bore size in mm (32 / 40 / 50 / 63 / 80 / 100 / 125). |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensors. |
JSI-family variants: JSI (double acting), JSID (double rod), JSIJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / TCM1 / TCM2. Thread PT (blank) / G.
Where the Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-100 Is Used
Short-Stroke Clamping
Dial in the exact clamping contact point on-site by shortening the extend stroke from 100 mm down to zero, accommodating varying part thicknesses without changing the cylinder.
Compact Ejector Station
Fit a 32 mm bore ejection mechanism into a tight machine cell where a longer ISO 15552 cylinder would not fit, using the G1/8 port and compact profile barrel.
Adjustable Stopper Gate
Set a precise product stop distance on a conveyor by adjusting the external stop screw, allowing quick changeovers between different product lengths on the same line.
Is the Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-100 the Right Cylinder?
The 100 mm adjustable window is ideal for sharing a single spare cylinder across multiple stroke variants or for dialing in exact end positions on-site. JSIJ mounting options include Basic, FA, LB, TC, TCM1, and TCM2. Remember that this non-magnetic SKU cannot take sensors; choose the -S variant for CMSE/DMSE switches. For any stroke length of 300 mm or longer, always use a guide rail to prevent side-load damage to the rod.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Set cushions to minimum, then release gradually.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-100 FAQ
It features a 12 mm rod, M10x1.25 rod thread, G1/8 port, and 20 mm adjustable cushions at both ends.
The nominal 100 mm stroke is the maximum. An external stop screw lets you shorten the extend stroke on-site by up to 100 mm, meaning the usable extend stroke is 0 to 100 mm. The retract end is fixed, and this stop mechanism only sets the end position rather than holding the load.
