Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-30
The AirTAC JSIJ32~50 Adjustable Cylinder JSIJ32X100-30 is a genuine double acting, double rod, adjustable stroke JIS-standard air cylinder with a Ø32mm bore and 100mm stroke, G1/8 air ports and adjustable end cushioning. Its no-tie-rod, hard-anodized profile barrel is more compact than an ISO 15552 cylinder of the same bore — a space-saver on tight machines.
- BoreØ32 mm
- Stroke100 mm
- Port sizeG1/8
- Acting typeDouble acting, double rod, adjustable stroke
- Rod threadM10×1.25
- CushionAdjustable, 20 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-30
Its extruded hard-anodized aluminium barrel omits external rods, making it noticeably shorter than a same-bore ISO 15552 unit. The G1/8 port keeps air supply neatly scaled to this smaller frame.
The -30 code means an external adjuster can shorten the extend stroke on-site by up to 30 mm, giving a usable 70-100 mm range while the retract end stays fixed. You can fine-tune the end position without swapping the cylinder, which is ideal for shared spares across stroke variants.
Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-30 Technical Specifications
| Model | Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-30 |
|---|---|
| Series | JSI JIS-standard profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 100 mm |
| Acting type | Double acting, double rod, adjustable stroke |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 20 mm |
| Max standard stroke | Up to 1000 mm |
Specifications follow the official AirTAC JSI (JIS standard) datasheet. Confirm against the product label before installation. Thread options: PT (blank) / G. Barrel: hard-anodized aluminum profile (no tie rods).
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | 484 N |
| Max (@1.0 MPa) | 70 kgf | |
JSIJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative).
Model Code: Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-30
| JSIJ | JIS-standard profile cylinder (adjustable-stroke type). |
|---|---|
| 32 | Bore size in mm (32 / 40 / 50 / 63 / 80 / 100 / 125). |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensors. |
JSI-family variants: JSI (double acting), JSID (double rod), JSIJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / TCM1 / TCM2. Thread PT (blank) / G.
Where the Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-30 Is Used
Stopper Position Tuning
Dial in the exact 70-100 mm extend stop on a small parts diverter without machining a new mount.
Compact Clamp Arm
Fit the short JIS profile into a dense fixture and tweak the 30 mm window to clamp varying heights.
Is the Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-30 the Right Cylinder?
Size this 32 mm bore against the 40 mm option if you need more push (628 N at 0.5 MPa), as the 32 mm sits at the low edge of the range. The adjustable stroke shines when you need on-site end-position tuning or want a single spare to cover several stroke variants. JSIJ mounting choices include Basic, FA, LB, TC, TCM1, and TCM2. Because this is a no-S SKU, it cannot take a magnetic sensor; add the -S variant for CMSE/DMSE switches. For any stroke over 300 mm, always guide the load to prevent side-load wear.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Set cushions to minimum, then release gradually.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-30 FAQ
The air port is G1/8.
The 100 mm nominal stroke is the maximum. An external adjuster lets you shorten the extend stroke on-site by up to 30 mm, yielding a 70-100 mm usable range. The retract end is fixed.
