Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-50
The AirTAC JSIJ32~50 Adjustable Cylinder JSIJ32X100-50 is a genuine double acting, double rod, adjustable stroke JIS-standard air cylinder with a Ø32mm bore and 100mm stroke, G1/8 air ports and adjustable end cushioning. Its no-tie-rod, hard-anodized profile barrel is more compact than an ISO 15552 cylinder of the same bore — a space-saver on tight machines.
- BoreØ32 mm
- Stroke100 mm
- Port sizeG1/8
- Acting typeDouble acting, double rod, adjustable stroke
- Rod threadM10×1.25
- CushionAdjustable, 20 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-50
Its extruded hard-anodized aluminium barrel omits external rods, making the overall body shorter than a same-bore ISO 15552 unit.
The -50 code means an external adjuster can shorten the 100 mm extend stroke on-site by up to 50 mm, yielding a usable 50-100 mm window without swapping the cylinder. Pneumatic connections use a G1/8 port, and the retract end remains fixed.
Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-50 Technical Specifications
| Model | Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-50 |
|---|---|
| Series | JSI JIS-standard profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 100 mm |
| Acting type | Double acting, double rod, adjustable stroke |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 20 mm |
| Max standard stroke | Up to 1000 mm |
Specifications follow the official AirTAC JSI (JIS standard) datasheet. Confirm against the product label before installation. Thread options: PT (blank) / G. Barrel: hard-anodized aluminum profile (no tie rods).
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | 484 N |
| Max (@1.0 MPa) | 70 kgf | |
JSIJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative).
Model Code: Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-50
| JSIJ | JIS-standard profile cylinder (adjustable-stroke type). |
|---|---|
| 32 | Bore size in mm (32 / 40 / 50 / 63 / 80 / 100 / 125). |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensors. |
JSI-family variants: JSI (double acting), JSID (double rod), JSIJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / TCM1 / TCM2. Thread PT (blank) / G.
Where the Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-50 Is Used
Stopper Position Tuning
Dial in the exact 50-100 mm extend stop on a conveyor diverter without machining a new mount.
Small Part Ejection
Fine-tune the ejection reach of a 32 mm bore assembly station to handle varying product widths.
Compact Clamping
Fit a short JIS-profile clamp into a tight cell and adjust the 50 mm stroke window on-site.
Is the Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-50 the Right Cylinder?
When sizing this 32 mm bore, step down only if your load is trivial, as it is the smallest standard size; step up to a 40 mm bore if you need 628 N at 0.5 MPa. The adjustable stroke is ideal for tuning end positions on-site or keeping one spare for multiple stroke variants. Mounting options include FA, LB, TC, TCM1, and TCM2. Since this SKU lacks the -S suffix, it cannot accept a magnetic sensor; choose the -S version for CMSE or DMSE switches. For any stroke over 300 mm, always guide the load to prevent side-load wear.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Set cushions to minimum, then release gradually.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-50 FAQ
At 0.5 MPa it pushes 402 N and pulls 345 N. At 0.7 MPa it pushes 563 N and pulls 483 N. The theoretical maximum force is 82 kgf at 1.0 MPa. The air port is G1/8.
The 100 mm nominal stroke is the maximum. An external stop screw lets you shorten the extend stroke by up to 50 mm on-site, giving a usable 50-100 mm range. The retract end is fixed, and this stop only sets position; it does not lock the load.
