Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-75
The AirTAC JSIJ32~50 Adjustable Cylinder JSIJ32X100-75 is a genuine double acting, double rod, adjustable stroke JIS-standard air cylinder with a Ø32mm bore and 100mm stroke, G1/8 air ports and adjustable end cushioning. Its no-tie-rod, hard-anodized profile barrel is more compact than an ISO 15552 cylinder of the same bore — a space-saver on tight machines.
- BoreØ32 mm
- Stroke100 mm
- Port sizeG1/8
- Acting typeDouble acting, double rod, adjustable stroke
- Rod threadM10×1.25
- CushionAdjustable, 20 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-75
The hard-anodized aluminum profile barrel makes it shorter and more compact than a same-bore ISO 15552 cylinder, saving valuable space. It uses a G1/8 air port and an M10x1.25 rod thread.
The external stop screw lets you shorten the extend stroke by up to 75 mm on-site, giving a usable range of 25-100 mm without changing the cylinder body. This mechanism sets the end position but is not a load lock. A plain cylinder drifts on air loss, so add an external rod lock for held loads.
Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-75 Technical Specifications
| Model | Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-75 |
|---|---|
| Series | JSI JIS-standard profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 100 mm |
| Acting type | Double acting, double rod, adjustable stroke |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 20 mm |
| Max standard stroke | Up to 1000 mm |
Specifications follow the official AirTAC JSI (JIS standard) datasheet. Confirm against the product label before installation. Thread options: PT (blank) / G. Barrel: hard-anodized aluminum profile (no tie rods).
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | 484 N |
| Max (@1.0 MPa) | 70 kgf | |
JSIJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative).
Model Code: Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-75
| JSIJ | JIS-standard profile cylinder (adjustable-stroke type). |
|---|---|
| 32 | Bore size in mm (32 / 40 / 50 / 63 / 80 / 100 / 125). |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensors. |
JSI-family variants: JSI (double acting), JSID (double rod), JSIJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / TCM1 / TCM2. Thread PT (blank) / G.
Where the Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-75 Is Used
Stopper Cylinder Tuning
Fine-tune the extend stop position on-site by up to 75 mm to accommodate different product widths on a single conveyor line.
Compact Pressing
Performs light-duty pressing tasks in tight spaces where the shorter JIS profile barrel offers a clear assembly advantage.
Is the Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-75 the Right Cylinder?
When sizing this 32 mm bore unit, consider stepping up to the 40 mm bore if your application exceeds the 345 N pull force at 0.5 MPa, or dropping to a smaller body if the load is minimal. The adjustable stroke is ideal for sharing a single spare across multiple stroke variants or fine-tuning the end position during machine commissioning. Mounting options include FA, LB, TC, TCM1, and TCM2 brackets. Because this specific SKU lacks the -S magnet, it cannot accept CMSE or DMSE sensors. For any stroke over 300 mm, always use a guide to prevent side-load damage.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Set cushions to minimum, then release gradually.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X100-75 FAQ
It features a G1/8 air port and a 20 mm adjustable air cushion at each end.
The nominal 100 mm stroke is the maximum. An external stop screw allows you to shorten the extend stroke by up to 75 mm on-site, yielding a usable extend range of 25-100 mm. The retract end remains fixed, and this stop only sets the end position rather than locking the load.
