Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X125-100S
The AirTAC JSIJ32~50 Adjustable Cylinder JSIJ32X125-100S is a genuine double acting, double rod, adjustable stroke JIS-standard air cylinder with a Ø32mm bore and 125mm stroke, G1/8 air ports and adjustable end cushioning. Its no-tie-rod, hard-anodized profile barrel is more compact than an ISO 15552 cylinder of the same bore — a space-saver on tight machines.
- BoreØ32 mm
- Stroke125 mm
- Port sizeG1/8
- Acting typeDouble acting, double rod, adjustable stroke
- Rod threadM10×1.25
- CushionAdjustable, 20 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X125-100S
The hard-anodized aluminum extruded barrel keeps the assembly light without external support rods.
The -100S designation means the external adjuster can shorten the extend stroke on-site by up to 100 mm, yielding a usable forward travel range of 25 to 125 mm while the retract end remains fixed. This lets you fine-tune the end position mechanically without swapping the cylinder. The built-in magnet works seamlessly with CMSE/DMSE sensors in the side grooves for precise position detection.
Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X125-100S Technical Specifications
| Model | Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X125-100S |
|---|---|
| Series | JSI JIS-standard profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 125 mm |
| Acting type | Double acting, double rod, adjustable stroke |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 20 mm |
| Max standard stroke | Up to 1000 mm |
Specifications follow the official AirTAC JSI (JIS standard) datasheet. Confirm against the product label before installation. Thread options: PT (blank) / G. Barrel: hard-anodized aluminum profile (no tie rods).
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | 484 N |
| Max (@1.0 MPa) | 70 kgf | |
JSIJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative).
Model Code: Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X125-100S
| JSIJ | JIS-standard profile cylinder (adjustable-stroke type). |
|---|---|
| 32 | Bore size in mm (32 / 40 / 50 / 63 / 80 / 100 / 125). |
| ×125 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensors. |
JSI-family variants: JSI (double acting), JSID (double rod), JSIJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / TCM1 / TCM2. Thread PT (blank) / G.
Where the Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X125-100S Is Used
Pick-and-Place Dial Tuning
Dial in the exact 25-125 mm extend reach for a small parts gripper on the fly, ensuring precise placement without machining new hard stops.
Variable Depth Carton Sealing
Adjust the forward stroke on-site to match different box depths, using the compact 32 mm profile to fit tight packaging cell clearances.
Shared Spare Cylinder
Keep one cylinder as a plant-wide spare for multiple 32 mm machines, shortening the extend travel from 125 mm down to 25 mm as each station requires.
Is the Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X125-100S the Right Cylinder?
The adjustable 25-125 mm extend window is ideal for sharing a single spare cylinder across multiple stroke variants or dialing in exact end positions on-site. Mounting options include FA, LB, TC, TCM1, and TCM2 brackets. The -S magnet supports CMSE/DMSE switches for end-of-stroke confirmation. For any stroke at or above 300 mm, always use a guide rail to prevent side-load wear on the rod seals.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Set cushions to minimum, then release gradually.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac JSIJ32~50 Adjustable Cylinder JSIJ32X125-100S FAQ
The theoretical maximum force is 82 kgf at 1.0 MPa. This 32 mm bore unit uses a G1/8 air port and features a 12 mm piston rod.
The nominal stroke is 125 mm, but an external adjuster lets you shorten the extend stroke on-site by up to 100 mm, giving a usable forward range of 25 to 125 mm. The retract end is fixed. This mechanism sets the end position and decelerates the load, but it is not a load lock; for holding a load on air loss, use an external rod lock or pilot-operated check valve.
Authorized Export Seller
Genuine AirTAC parts produced by AirTAC factory.
1-Year Warranty
Covers non-human-caused product damage.
Fast Dispatch
Standard models are processed and dispatched in 3-5 business days.
Fast Reply
Most inquiries answered within 7-8 hours.
