Airtac PBD Pen-shaped Double Rod Cylinder PBD10X10
The AirTAC PBD Pen-shaped Double Rod Cylinder PBD10X10 is a double-acting pen-size mini cylinder with a piston rod protruding from both covers. The twin rods share one piston, giving equal push and pull force, resisting rotation and providing a spare mounting or sensing end on a Ø10mm bore, 10mm stroke.
- BoreØ10 mm
- Stroke10 mm
- Port sizeM5×0.8
- Acting typeDouble acting, double rod
- Rod threadM8×1.0
- ForceEqual both ways
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PBD Pen-shaped Double Rod Cylinder PBD10X10
The AirTAC PBD10X10 is a double-acting, double-rod pen-size mini cylinder. A Ø4 mm piston rod protrudes from both covers on a single piston, meaning both chambers act on the same rod-side annular area. This geometry yields equal push and pull forces, giving you 33 N of thrust in both directions at 0.5 MPa.
The twin rods resist twist better than a single rod, improving guidance for light tooling. The second rod end can carry a sensor flag or external stop without extra hardware. Built with SUS304 stainless steel and a fixed TPU bumper at each end, this slim body uses an M5x0.8 air port and M8x1.0 rod-end thread.
Airtac PBD Pen-shaped Double Rod Cylinder PBD10X10 Technical Specifications
| Model | Airtac PBD Pen-shaped Double Rod Cylinder PBD10X10 |
|---|---|
| Series | PBD JIS pen-size double-rod cylinder |
| Bore size | Ø10 mm |
| Rod diameter | Ø4 mm (both ends) |
| Stroke | 10 mm |
| Acting type | Double acting, double rod |
| Port size | M5×0.8 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 0.7 MPa |
| Proof pressure | 1.2 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 800 mm/s |
| Cushion | Elastic bumper (both ends) |
| Max standard stroke | Up to 100 mm |
Both chambers act on the rod-side annular area, so push and pull forces are equal. Piston rod and barrel are stainless steel. Confirm against the product label before installation.
Theoretical Output Force (Ø10mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 33.0 N | 33.0 N |
| 0.7 MPa (max) | 46.2 N | 46.2 N |
Because a rod occupies both chambers, the effective area is identical on each side — push and pull forces match. Values are from the AirTAC thrust table (rod-side / pull column). Size with a friction margin.
Model Code: Airtac PBD Pen-shaped Double Rod Cylinder PBD10X10
| PBD | JIS pen-size double-rod mini-cylinder series. |
|---|---|
| 10 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| S | Built-in magnet for magnetic-switch position sensing (omit = no magnet). |
Fixed body — no separate back-cover code. Mounting accessories: LB, FA. Related PB-family variants: PB (single rod), PBJ (adjustable stroke), PBR (front-mount).
Where the Airtac PBD Pen-shaped Double Rod Cylinder PBD10X10 Is Used
Dual-Side Transfer
Move a part 10 mm to the right on the push stroke and a second part to the left on the pull stroke, exploiting the equal force for a balanced dual-side transfer jig.
Symmetric Clamp
Clamp a delicate workpiece from both sides simultaneously using the twin rods, ensuring centered holding without inducing rotational torque on the cylinder body.
Sensor-Flagged Index
Use the primary rod end for the 10 mm indexing motion while attaching a physical sensor flag to the spare rear rod end to confirm position without loading the working side.
Is the Airtac PBD Pen-shaped Double Rod Cylinder PBD10X10 the Right Cylinder?
For this 10 mm bore, the 10 mm stroke offers very short travel. If you need less force, stepping down to a 6 mm bore gives 10.6 N at 0.5 MPa. If you need more power, stepping up to a 12 mm bore provides 46.7 N at 0.5 MPa. All three options deliver identical push and pull forces.
Because rods exit both ends, you must allow clearance across the full 10 mm stroke at both covers. Confirm your ordering essentials: 10 mm bore, 10 mm stroke, no magnet, and your preferred mounting option. The thin Ø4 mm rod is built for coaxial thrust, so add an external linear guide if your application involves off-axis loads.
Quick checklist
- ✓ Need equal force in both directions
- ✓ Second rod end for a sensor / stop / flag
- ✓ Better anti-rotation than a single rod
- ✓ Magnet (S) for sensors?
- ✓ Clearance for the rod on both ends
- ✓ Keep the load coaxial — avoid side load
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 0.7 MPa operating pressure.
- check Leave clearance for the rod at both ends.
- check Keep the load coaxial; avoid side load on the thin rods.
- check Do not dismantle the front or back cover.
- check Fit dust caps to ports during long-term storage.
Airtac PBD Pen-shaped Double Rod Cylinder PBD10X10 FAQ
The PBD10X10 provides equal push and pull forces of 33 N at 0.5 MPa and 46.2 N at the maximum operating pressure of 0.7 MPa. Both directions generate the same thrust because the double-rod design acts on the same annular area.
No, a plain double-acting cylinder drifts when air loss occurs. The fixed TPU bumper only decelerates the piston near the stroke end; it is not a lock or brake. You must use an external stop or rod lock for fail-safe load holding.
