Airtac SAID32 Double Rod Cylinder SAID32X1000S
The AirTAC SAID32 Double Rod Cylinder SAID32X1000S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø32mm bore and 1000mm stroke, G1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ32 mm
- Stroke1000 mm
- Port sizeG1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 27 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAID32 Double Rod Cylinder SAID32X1000S
The AirTAC SAID32X1000-S is a double-acting, double-rod profile cylinder that fully complies with the ISO 15552 mounting interface. Because a carbon steel rod exits both end covers, the effective piston area is identical on extend and retract, yielding an equal 345 N of force in each direction at 0.5 MPa. This specific 1000 mm stroke configuration is a non-standard, made-to-order variant exceeding the 32 mm bore's 500 mm standard limit.
Equipped with a magnet (-S), it supports AirTAC CMSE reed and DMSE electronic sensors housed within the dual side grooves of the extruded aluminum barrel. The through-rod design allows you to mount the primary workpiece on the front rod end while using the rear protrusion to drive a secondary mechanism, actuate a limit flag, or provide dual-side anti-rotation guidance.
Airtac SAID32 Double Rod Cylinder SAID32X1000S Technical Specifications
| Model | Airtac SAID32 Double Rod Cylinder SAID32X1000S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | — |
| Max (@1.0 MPa) | 70 kgf | |
Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAID32 Double Rod Cylinder SAID32X1000S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 32 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAID32 Double Rod Cylinder SAID32X1000S Is Used
Symmetric Force Transfer
Drives a dual-station shuttle where the 345 N push and pull forces must be perfectly matched, ensuring consistent cycle times in both directions without pressure spikes.
Anti-Rotation Sliding Gate
Actuates a long 1000 mm guided gate using the twin rod ends to resist torsional twisting, keeping the load stable despite the extended reach.
Rear-Cam Limit Actuation
Mounts the primary tool on the front rod and a cam on the rear protrusion to physically trigger secondary mechanical valves or sensors at mid-stroke.
Is the Airtac SAID32 Double Rod Cylinder SAID32X1000S the Right Cylinder?
Choose this 32 mm bore when an application demands perfectly symmetric force and speed, generating 345 N both ways at 0.5 MPa. If your mechanism requires less force, stepping down is not an option below 32 mm in this series, but stepping up to a 40 mm bore increases the bidirectional output to 528 N. Unlike a single-rod SAI cylinder, this double-rod SAID prevents rotational torque on the load by guiding it from both ends. Note that the overall physical length is greater than a single-rod cylinder because the rear rod protrudes, requiring extra clearance in your machine layout.
At 1000 mm of stroke, the 12 mm rod is highly susceptible to bending under side loads, so an external linear guide is mandatory to prevent premature rod-bearing wear. This cylinder uses a PT tapered port thread and supports Basic, FA, LB, TC, FTC, TCM1, and TCM2 mounts (omitting FB, CA, CB, and CR). It is dimensionally interchangeable with other ISO 15552 profile cylinders. Remember that the adjustable air cushions only decelerate the piston near stroke ends; they do not hold the load if air pressure is lost. For dead-load holding, use an external pilot-operated check valve or consider a BSAID clamp-lock cylinder.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAID32 Double Rod Cylinder SAID32X1000S FAQ
Because the rod occupies both sides of the piston, the force is identical in both directions. It provides 345 N at 0.5 MPa, 483 N at 0.7 MPa, and 621 N at 0.9 MPa for both extension and retraction.
Yes, the SAID32X1000-S is dimensionally interchangeable per ISO 15552 standards. You can drop it in for other ISO 15552 profile cylinders of the same bore and stroke, provided your mounting style is Basic, FA, LB, TC, FTC, TCM1, or TCM2.
