Airtac SAID32 Double Rod Cylinder SAID32X15
The AirTAC SAID32 Double Rod Cylinder SAID32X15 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø32mm bore and 15mm stroke, G1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ32 mm
- Stroke15 mm
- Port sizeG1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 27 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAID32 Double Rod Cylinder SAID32X15
The AirTAC SAID32X15 is a double-acting, double-rod ISO 15552 profile cylinder featuring a 32mm bore and 15mm stroke. Because the piston rod extends from both end covers, the effective annulus area is identical on extension and retraction. This design yields equal push and pull forces, providing exactly 345 N of thrust each way at 0.5 MPa.
A rod exits both ends to allow mounting a workpiece on the front and a cam or position flag on the rear for dual-side sensing. The extruded aluminum barrel includes sensor grooves on both sides, and while this unit lacks a magnet, adding the -S option enables compatibility with AirTAC CMSE reed and DMSE electronic switches.
Airtac SAID32 Double Rod Cylinder SAID32X15 Technical Specifications
| Model | Airtac SAID32 Double Rod Cylinder SAID32X15 |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 15 mm |
| Acting type | Double acting |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | — |
| Max (@1.0 MPa) | 70 kgf | |
Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAID32 Double Rod Cylinder SAID32X15
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 32 | Bore size in mm. |
| ×15 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAID32 Double Rod Cylinder SAID32X15 Is Used
Symmetric Force Transfer
Drives a lightweight transfer arm where the 345 N output must remain identical in both directions to maintain precise timing without recalibrating pressure.
Anti-Rotation Slides
Guides a short-stroke vertical slide using the twin-rod structure to prevent torsional twisting that a single-rod cylinder might allow under offset loads.
Rear-Cam Actuation
Mounts the primary tool on the front rod while utilizing the rear protruding rod end to trigger a mechanical limit switch or secondary cam mechanism.
Is the Airtac SAID32 Double Rod Cylinder SAID32X15 the Right Cylinder?
Select this 32mm bore model when an application demands perfectly symmetric force and speed in a highly compact footprint. If your mechanism requires slightly higher thrust, stepping up to the 40mm bore raises the bidirectional output to 528 N at 0.5 MPa. Choose the SAID twin-rod configuration over a single-rod SAI when you need superior anti-rotation guidance or must drive a secondary mechanism from the rear rod end.
As a true ISO 15552 profile cylinder, it drops in seamlessly with other standard 32mm interface components. It uses PT tapered ports and supports a reduced mounting set (Basic, FA, LB, TC, FTC, TCM1, TCM2) omitting the FB, CA, CB, and CR variants. Note that the adjustable air cushions only decelerate the piston near stroke end; this cylinder will drift and cannot hold a load if air pressure is lost. For locking requirements, consider an external rod lock or the SAIL series.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAID32 Double Rod Cylinder SAID32X15 FAQ
Because it is a double-rod cylinder, the force is equal in both directions. It provides 345 N at 0.5 MPa, 483 N at 0.7 MPa, and 621 N at 0.9 MPa for both extension and retraction.
Yes, it is dimensionally interchangeable per ISO 15552. It supports a specific subset of mounts including Basic, FA, LB, TC, FTC, TCM1, and TCM2, but omits FB, CA, CB, and CR styles.
