AirTAC SAI Series · ISO 15552 Cylinder

Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-10

The AirTAC SAIJ40 Adjustable Cylinder SAIJ40X100-10 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø40mm bore and 100mm stroke, G1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ40 mm
  • Stroke100 mm
  • Port sizeG1/4
  • Acting typeDouble acting
  • Rod threadM12×1.25
  • CushionAdjustable, 30 mm
$70.48 $77.98Save 9% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SAIJ40 stroke, mounting and version on one page All SAIJ40 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-10

The AirTAC SAIJ40X100-10 is a double-acting ISO 15552 profile cylinder featuring a rear-mounted stroke adjuster. It provides a usable travel window of 90-100 mm, allowing you to dial in the exact end position during commissioning without swapping hardware. The extruded aluminum barrel includes sensor grooves on both sides for flexible mounting of CMSE reed or DMSE electronic switches, though a magnet is not installed on this base unit. The mounting set covers Basic, FA, LB, TC, FTC, TCM1, and TCM2, omitting the FB, CA, CB, and CR options.

Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-10 Technical Specifications

ModelAirtac SAIJ40 Adjustable Cylinder SAIJ40X100-10
SeriesSAI ISO 15552 profile cylinder
Bore sizeØ40 mm
Stroke100 mm
Acting typeDouble acting
Port sizeG1/4
Rod threadM12×1.25
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 800 mm/s
CushionAdjustable, 30 mm
Max strokeUp to 1200 mm

Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.

Theoretical Output Force (Ø40mm)

PressurePush forcePull force
0.5 MPa528 N528 N
0.7 MPa739 N—
Max (@1.0 MPa)108 kgf

Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-10

SAIISO 15552 profile-barrel cylinder series.
40Bore size in mm.
×100Stroke length in mm.
-SOptional built-in magnet for sensor position sensing.

Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.

Where the Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-10 Is Used

tune

Stroke Tuning

Dial in the 90-100 mm travel window during machine setup to hit exact retract positions without adding external stops.

settings_input_component

Product Changeover

Quickly adjust the end-stop distance when switching product sizes on a conveyor or assembly line.

Is the Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-10 the Right Cylinder?

The 10 mm adjustment range is perfect for product changeovers on a line, acting as an external stop rather than a fixed SAI cylinder. Because the rear adjuster and air cushions only decelerate the load, this cylinder cannot hold position without live air—use SAIL or BSAI for true locking. For ISO 15552 replacement matching, verify the 100 mm stroke, 10 mm adjuster, PT port, and mounting style.

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/NPT/G)
  • ✓ Magnet (-S) for sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-10 FAQ

At 0.7 MPa the push force increases to 879 N.

The rear adjuster screw lets you shorten the 100 mm nominal stroke by up to 10 mm, creating a 90-100 mm usable travel window for fine-tuning without replacing the cylinder.
