AirTAC SAI Series · ISO 15552 Cylinder

Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-100

The AirTAC SAIJ40 Adjustable Cylinder SAIJ40X100-100 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø40mm bore and 100mm stroke, G1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ40 mm
  • Stroke100 mm
  • Port sizeG1/4
  • Acting typeDouble acting
  • Rod threadM12×1.25
  • CushionAdjustable, 30 mm
$70.48 $77.98Save 9% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SAIJ40 stroke, mounting and version on one page All SAIJ40 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-100

The AirTAC SAIJ40X100-100 is a double-acting ISO 15552 profile cylinder featuring a rear stroke adjuster that permits the effective travel to be dialed back by up to 100 mm, yielding a highly flexible 0 to 100 mm usable window from a 100 mm nominal stroke. The extruded aluminum barrel includes sensor grooves on both sides for straightforward detection add-ons.

This adjustable design eliminates the need to physically swap cylinders or bolt on external stops when tuning end positions during commissioning. It uses a reduced mounting set of Basic, FA, LB, TC, FTC, TCM1, and TCM2, omitting the FB, CA, CB, and CR options found on some standard variants. The carbon steel piston rod features an M12x1.25 thread, providing a robust interface for your tooling.

Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-100 Technical Specifications

ModelAirtac SAIJ40 Adjustable Cylinder SAIJ40X100-100
SeriesSAI ISO 15552 profile cylinder
Bore sizeØ40 mm
Stroke100 mm
Acting typeDouble acting
Port sizeG1/4
Rod threadM12×1.25
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 800 mm/s
CushionAdjustable, 30 mm
Max strokeUp to 1200 mm

Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.

Theoretical Output Force (Ø40mm)

PressurePush forcePull force
0.5 MPa528 N528 N
0.7 MPa739 N—
Max (@1.0 MPa)108 kgf

Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-100

SAIISO 15552 profile-barrel cylinder series.
40Bore size in mm.
×100Stroke length in mm.
-SOptional built-in magnet for sensor position sensing.

Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.

Where the Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-100 Is Used

tune

Product Changeovers

Dial in the exact end position for different product sizes on a single machine without physically swapping out the entire actuator.

settings_input_component

Commissioning Calibration

Fine-tune the travel distance during initial machine setup to perfect timing and avoid mechanical crashes.

precision_manufacturing

Variable End Stops

Provide a customizable physical stop for tooling heads that need to operate at differing depths across multiple production runs.

Is the Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-100 the Right Cylinder?

Select this 40 mm bore model when an application requires a highly variable end-stop, as the 100 mm adjustment range allows the stroke to be fine-tuned anywhere from 0 to 100 mm. Because the rear adjuster acts only as a travel stop and the air cushions manage deceleration, this cylinder cannot hold a load without live air pressure; for fail-safe load holding, consider the SAIL or BSAI series instead.

When replacing an ISO 15552 cylinder, match the 40 mm bore, 100 mm nominal stroke, 100 mm adjustment code, PT tapered port thread, and the specific mounting accessory. The standard carbon steel rod and absence of a magnet mean position sensing requires adding a separate external switch or specifying a different configuration.

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/NPT/G)
  • ✓ Magnet (-S) for sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-100 FAQ

At the maximum operating pressure of 1.0 MPa, it delivers up to 128 kgf.

The rear adjuster screw allows you to trim the effective travel back by up to 100 mm. Because the nominal stroke is 100 mm, you can set the usable travel anywhere within a 0 to 100 mm window without changing the cylinder itself.
