AirTAC SAI Series · ISO 15552 Cylinder

Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-100S

The AirTAC SAIJ40 Adjustable Cylinder SAIJ40X100-100S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø40mm bore and 100mm stroke, G1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ40 mm
  • Stroke100 mm
  • Port sizeG1/4
  • Acting typeDouble acting
  • Rod threadM12×1.25
  • CushionAdjustable, 30 mm
$73.27 $80.77Save 9% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SAIJ40 stroke, mounting and version on one page All SAIJ40 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-100S

The AirTAC SAIJ40X100-100-S is a double-acting ISO 15552 profile cylinder equipped with a rear stroke adjuster, enabling a usable travel window of 0-100 mm. Because it carries the -S magnet, it directly supports AirTAC CMSE reed and DMSE electronic solid-state sensors housed in the dual-side extruded barrel grooves.

This adjustable model is built for commissioning flexibility, allowing you to dial in the exact retract end-position without swapping hardware or adding external stops. The rear screw acts purely as a travel stop to set deceleration and does not lock the load without live air. It uses a reduced mounting set (Basic, FA, LB, TC, FTC, TCM1, TCM2) and omits FB, CA, CB, and CR brackets.

Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-100S Technical Specifications

ModelAirtac SAIJ40 Adjustable Cylinder SAIJ40X100-100S
SeriesSAI ISO 15552 profile cylinder
Bore sizeØ40 mm
Stroke100 mm
Acting typeDouble acting
Port sizeG1/4
Rod threadM12×1.25
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 800 mm/s
CushionAdjustable, 30 mm
Max strokeUp to 1200 mm

Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.

Theoretical Output Force (Ø40mm)

PressurePush forcePull force
0.5 MPa528 N528 N
0.7 MPa739 N—
Max (@1.0 MPa)108 kgf

Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-100S

SAIISO 15552 profile-barrel cylinder series.
40Bore size in mm.
×100Stroke length in mm.
-SOptional built-in magnet for sensor position sensing.

Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.

Where the Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-100S Is Used

tune

Changeover Dial-In

Fine-tune the retract position during machine format changes, adjusting the 0-100 mm travel window to accommodate varying product lengths without disassembling the pneumatic setup.

precision_manufacturing

End-Stop Calibration

Set exact end-of-stroke positions during initial commissioning, using the rear stopper to perfect the mechanical timing of your assembly process.

settings_input_component

Sensor Integration

Leverage the integrated -S magnet and dual sensor grooves to mount CMSE or DMSE switches for precise position feedback across the adjusted travel range.

Is the Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-100S the Right Cylinder?

Select this 40 mm bore cylinder when an application requires variable end-stop tuning within a 0-100 mm range, making it superior to a fixed-stroke SAI for product changeovers. If your process needs higher force, stepping up to a 50 mm bore raises the 0.5 MPa push thrust to 982 N. To replace an existing ISO 15552 cylinder, match the 40 mm bore, 100 mm nominal stroke, 100 mm adjustment range, PT tapered port threads, and the -S magnet requirement.

For any stroke of 300 mm or more, an external guide is required to prevent rod side-load damage, though this 100 mm unit is well within safe limits. Remember that the rear adjuster only sets the travel end; for true load-holding without live air pressure, consider an AirTAC SAIL or BSAI series cylinder.

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/NPT/G)
  • ✓ Magnet (-S) for sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-100S FAQ

At 0.7 MPa, the push force increases to 879 N.

The rear adjuster screw acts as a mechanical stop, allowing you to shorten the effective travel anywhere within a 0-100 mm window from the nominal 100 mm stroke. It sets the end position but does not hold the load without live air pressure.
