The AirTAC SAIJ40 Adjustable Cylinder SAIJ40X100-10S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø40mm bore and 100mm stroke, G1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
The AirTAC SAIJ40X100-10-S is a double-acting, double-rod ISO 15552 profile cylinder equipped with a rear stroke adjuster.
This bore size features a 16mm carbon steel rod with an M12x1.25 thread, paired with PT tapered port threading (G1/4). The integrated magnet (-S) supports position sensing using AirTAC CMSE reed or DMSE electronic solid-state switches housed in the dual-side sensor grooves.
| Model | Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-10S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø40 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | G1/4 |
| Rod thread | M12×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 30 mm |
| Max stroke | Up to 1200 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 528 N | 528 N |
| 0.7 MPa | 739 N | — |
| Max (@1.0 MPa) | 108 kgf | |
Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 40 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Dial in the 90-100mm travel window during product size changeovers to perfectly position parts without swapping out the entire actuator.
Trim the retract position by up to 10mm at commissioning to compensate for mechanical tolerance stack-up in fixturing.
The adjustable 10mm window is selected over a fixed SAI cylinder when you need to dial in the exact end-stop on a machine changeover without adding external stops. For any stroke of 300mm or more, ensure an external guide supports the load to prevent rod side-load wear.
When matching an ISO 15552 replacement, verify the 40mm bore, 100mm stroke, 10mm adjustment range, PT port thread, and the -S magnet requirement. Remember that the rear adjuster acts only as a travel stop and does not hold the load without live air; for dead-air locking, consider the SAIL or BSAI series.
Quick checklist
The rear adjuster screw allows you to shorten the effective stroke by up to 10mm, creating a 90-100mm travel window. It acts as a mechanical stop to fine-tune the end position without needing external stops.
At 0.7 MPa, the push force increases to 879N.
