The AirTAC SAIJ40 Adjustable Cylinder SAIJ40X100-20 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø40mm bore and 100mm stroke, G1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
The AirTAC SAIJ40X100-20 is a double-acting, double-rod ISO 15552 profile cylinder equipped with a rear stroke adjuster. It provides a nominal 100 mm stroke that can be fine-tuned down by up to 20 mm, giving you a precise 80-100 mm usable travel window during commissioning.
This model features a standard carbon steel piston rod and tapered PT ports. The rear adjuster acts purely as a mechanical stop to set the retract position and does not hold the load without live air pressure. For load-holding requirements, consider the SAIL or BSAI variants instead.
| Model | Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-20 |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø40 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | G1/4 |
| Rod thread | M12×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 30 mm |
| Max stroke | Up to 1200 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 528 N | 528 N |
| 0.7 MPa | 739 N | — |
| Max (@1.0 MPa) | 108 kgf | |
Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 40 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Dial in the exact retract distance within the 80-100 mm window during machine commissioning without changing the cylinder.
Quickly adjust the stroke by up to 20 mm to accommodate different product sizes on the same production line.
The adjustable stroke is ideal for applications requiring variable end-stops or frequent product changeovers, eliminating the need to swap out a fixed-stroke SAI cylinder or bolt on external stops. To match this ISO 15552 cylinder exactly, specify a 100 mm stroke, 20 mm adjustment, PT port thread, and no magnet.
Because the stroke is 100 mm, side-loading is minimal, but always ensure the mountings from the available SAIJ set (Basic, FA, LB, TC, FTC, TCM1, TCM2) align true with your load guide. Note that FB, CA, CB, and CR mounts are omitted from this series.
Quick checklist
It features a rear adjusting screw that acts as a mechanical stop, allowing you to shorten the effective stroke by up to 20 mm. This creates an 80-100 mm travel window, but the screw is a stop, not a lock, and requires live air to hold position.
At the maximum 1.0 MPa pressure, the push force increases to 1130 N.
