The AirTAC SAIJ40 Adjustable Cylinder SAIJ40X100-20S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø40mm bore and 100mm stroke, G1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
The AirTAC SAIJ40X100-20-S is a double-acting, double-rod ISO 15552 profile cylinder featuring a rear stroke adjuster. It provides a usable travel window of 80 to 100 mm, allowing you to dial back the nominal 100 mm stroke by up to 20 mm during commissioning without swapping out the unit.
This variant includes a standard carbon steel piston rod and a -S magnet for position sensing. The extruded aluminum barrel features sensor grooves on both sides, supporting AirTAC CMSE reed and DMSE electronic solid-state switches. It uses PT tapered ports (G1/4) and offers variable air cushions at both ends to manage end-of-stroke deceleration across its 30-800 mm/s speed range.
| Model | Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-20S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø40 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | G1/4 |
| Rod thread | M12×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 30 mm |
| Max stroke | Up to 1200 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 528 N | 528 N |
| 0.7 MPa | 739 N | — |
| Max (@1.0 MPa) | 108 kgf | |
Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 40 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Dial in the exact 80 to 100 mm retract position during machine setup without fabricating external stopper blocks or changing the cylinder.
Quickly adjust the end-stop to accommodate different package sizes on a packaging line, utilizing the 20 mm trim range.
The adjustable stroke is ideal for machine setups requiring variable end stops or fine end-position tuning during product changeovers, rather than installing a fixed-stroke SAI cylinder with external shims. For a complete ISO 15552 replacement match, specify the 40 mm bore, 100 mm stroke, 20 mm adjustment, PT port thread, and the -S magnet option.
The rear adjuster acts strictly as a travel stop to set the retract position, not as a locking device. It cannot hold a load without live air pressure; for true fail-safe load holding, consider an AirTAC SAIL or BSAI series cylinder instead. Mounting options for this series include Basic, FA, LB, TC, FTC, TCM1, and TCM2.
Quick checklist
It features a rear adjusting screw that allows you to shorten the effective stroke by up to 20 mm. This creates a usable travel window of 80 to 100 mm, letting you fine-tune the retract end-position at commissioning without replacing the cylinder.
