AirTAC SAI Series · ISO 15552 Cylinder

Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-30

The AirTAC SAIJ40 Adjustable Cylinder SAIJ40X100-30 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø40mm bore and 100mm stroke, G1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ40 mm
  • Stroke100 mm
  • Port sizeG1/4
  • Acting typeDouble acting
  • Rod threadM12×1.25
  • CushionAdjustable, 30 mm
$70.48 $77.98Save 9% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SAIJ40 stroke, mounting and version on one page All SAIJ40 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-30

The AirTAC SAIJ40X100-30 is a double-acting ISO 15552 profile cylinder equipped with a rear stroke adjuster, allowing you to dial back the 100 mm nominal travel by up to 30 mm. This creates a usable 70-100 mm end-position window, providing immediate fine-tuning at commissioning without swapping hardware.

The extruded aluminum barrel features sensor grooves on both sides for flexible switch mounting, though this specific configuration ships without a magnet. It uses a 16 mm carbon steel rod with an M12x1.25 thread, offering robust resistance to side loads, and connects via PT G1/4 tapered ports. The mounting interface supports Basic, FA, LB, TC, FTC, TCM1, and TCM2 brackets, deliberately omitting FB, CA, CB, and CR styles.

Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-30 Technical Specifications

ModelAirtac SAIJ40 Adjustable Cylinder SAIJ40X100-30
SeriesSAI ISO 15552 profile cylinder
Bore sizeØ40 mm
Stroke100 mm
Acting typeDouble acting
Port sizeG1/4
Rod threadM12×1.25
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 800 mm/s
CushionAdjustable, 30 mm
Max strokeUp to 1200 mm

Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.

Theoretical Output Force (Ø40mm)

PressurePush forcePull force
0.5 MPa528 N528 N
0.7 MPa739 N—
Max (@1.0 MPa)108 kgf

Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-30

SAIISO 15552 profile-barrel cylinder series.
40Bore size in mm.
×100Stroke length in mm.
-SOptional built-in magnet for sensor position sensing.

Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.

Where the Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-30 Is Used

tune

Machine Changeover

Dial in the 70-100 mm stroke window during product size changeovers to set new end positions without replacing the cylinder.

settings_input_component

Variable End Stops

Use the rear adjuster to fine-tune the retraction point at commissioning, avoiding the need to machine and install external mechanical stops.

Is the Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-30 the Right Cylinder?

The adjustable 70-100 mm travel window is ideal for applications requiring variable end-stops or frequent product size changeovers, eliminating the need to bolt on external stops or buy multiple fixed-stroke SAI cylinders.

Because this is a standard configuration without a magnet, position sensing requires adding one separately or confirming requirements before purchase. For any load-holding application without live air pressure, note that the rear adjuster and air cushions act only as travel stops and deceleration devices, not locks; you should instead look at the SAIL or BSAI series. To match this cylinder as an ISO 15552 replacement, verify the 40 mm bore, 100 mm stroke, 30 mm adjustment, PT G1/4 port, and your required mounting bracket.

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/NPT/G)
  • ✓ Magnet (-S) for sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-30 FAQ

If pressure is increased to 0.7 MPa, the push force rises to 879 N.

The rear adjuster screw lets you shorten the 100 mm nominal stroke by up to 30 mm, creating a usable travel window of 70 to 100 mm. It functions as a mechanical stop to set the end position and does not lock the load without live air pressure.
