The AirTAC SAIJ40 Adjustable Cylinder SAIJ40X100-30S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø40mm bore and 100mm stroke, G1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
The AirTAC SAIJ40X100-30-S is a double-acting ISO 15552 profile cylinder featuring a rear-mounted stroke adjuster. It provides a usable travel window of 70 to 100 mm, allowing you to dial back the 100 mm nominal stroke by up to 30 mm during machine commissioning. In the 40 mm bore class, it delivers 628 N of pull force at 0.5 MPa and reaches 1130 N at 0.9 MPa.
This unit includes a standard carbon steel rod with an M12x1.25 thread, paired with a PT tapered port. Equipped with a magnetic piston (-S), it supports AirTAC CMSE reed and DMSE solid-state sensors housed in the dual-side extruded barrel grooves. The SAIJ mounting set omits FB, CA, CB, and CR brackets, focusing strictly on Basic, FA, LB, TC, FTC, TCM1, and TCM2 interfaces.
| Model | Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-30S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø40 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | G1/4 |
| Rod thread | M12×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 30 mm |
| Max stroke | Up to 1200 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 528 N | 528 N |
| 0.7 MPa | 739 N | — |
| Max (@1.0 MPa) | 108 kgf | |
Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 40 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Dial in the exact 70 to 100 mm end-position during initial commissioning without swapping cylinders or bolting on external stops.
Quickly adjust the stroke length by up to 30 mm on packaging lines when handling slightly different product sizes.
Fine-tune the retract stroke on assembly fixtures to accommodate sensor variances or minor mechanical shifts.
Choose this 40 mm bore adjustable model when you need 628 N pull force at 0.5 MPa and precise end-position tuning without adding external stops. If your application requires less force, the 32 mm bore offers 345 N pull; if you need more clamping power, the 50 mm bore provides 825 N. The rear adjuster acts strictly as a travel stop to decelerate the load—it does not hold the load without live air. For load-holding requirements, consider the SAIL or BSAI series. The PT port and M12x1.25 rod thread handle moderate side loads well, but always guide unsupported rods.
Quick checklist
The nominal stroke is 100 mm, but the rear adjuster allows you to shorten the effective travel by up to 30 mm, creating a usable stroke window of 70 to 100 mm.
At 0.9 MPa, the push force increases to 1130 N.
