AirTAC SAI Series · ISO 15552 Cylinder

Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-40

The AirTAC SAIJ40 Adjustable Cylinder SAIJ40X100-40 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø40mm bore and 100mm stroke, G1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ40 mm
  • Stroke100 mm
  • Port sizeG1/4
  • Acting typeDouble acting
  • Rod threadM12×1.25
  • CushionAdjustable, 30 mm
$70.48 $77.98Save 9% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SAIJ40 stroke, mounting and version on one page All SAIJ40 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-40

The AirTAC SAIJ40X100-40 is a double-acting ISO 15552 profile cylinder featuring a rear stroke adjuster that allows you to trim the effective travel within a 60 to 100 mm window. The carbon steel piston rod features an M12x1.25 thread, providing a robust interface for mounting attachments.

Unlike a fixed-stroke SAI, this adjustable variant lets you fine-tune the retract end position during commissioning or product changeovers without swapping the barrel or adding external stops. The extruded aluminum profile includes sensor grooves on both sides for CMSE reed or DMSE electronic switches, though a magnet (-S suffix) is required to activate them. The rear adjuster acts purely as a travel stop and does not hold the load without live air pressure.

Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-40 Technical Specifications

ModelAirtac SAIJ40 Adjustable Cylinder SAIJ40X100-40
SeriesSAI ISO 15552 profile cylinder
Bore sizeØ40 mm
Stroke100 mm
Acting typeDouble acting
Port sizeG1/4
Rod threadM12×1.25
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 800 mm/s
CushionAdjustable, 30 mm
Max strokeUp to 1200 mm

Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.

Theoretical Output Force (Ø40mm)

PressurePush forcePull force
0.5 MPa528 N528 N
0.7 MPa739 N—
Max (@1.0 MPa)108 kgf

Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-40

SAIISO 15552 profile-barrel cylinder series.
40Bore size in mm.
×100Stroke length in mm.
-SOptional built-in magnet for sensor position sensing.

Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.

Where the Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-40 Is Used

tune

Machine Changeover

Dial in the 60 to 100 mm retract position during product size changeovers without physically swapping cylinders or reengineering external stop blocks.

precision_manufacturing

End-Position Tuning

Fine-tune the final resting point of the tooling at commissioning to absorb mechanical tolerances and achieve precise placement on the assembly.

conveyor_belt

Variable End Stops

Adjust the travel window on the fly for diverter gates or indexing mechanisms that handle multiple package sizes on a single conveyor line.

Is the Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-40 the Right Cylinder?

The PT tapered G1/4 port matches the standard airflow requirements for this bore size. Select the SAIJ adjustable series over the fixed SAI when your machine setup demands a variable end-stop to accommodate product size changes on a line.

For an exact ISO 15552 replacement match, ensure your specifications include a 40 mm bore, 100 mm nominal stroke, 40 mm adjustment range, PT port thread, and a mounting choice from the reduced SAIJ set: Basic, FA, LB, TC, FTC, TCM1, or TCM2 (this series omits FB, CA, CB, and CR). Because the stroke is 100 mm, side-load is minimal, but always guide long unsupported loads. If you need true load-holding without live air, consider the SAIL or BSAI series, as the SAIJ adjuster is not a lock.

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/NPT/G)
  • ✓ Magnet (-S) for sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-40 FAQ

If you increase the pressure to 0.7 MPa, the push force reaches 879 N.

The rear adjuster screw allows you to shorten the effective stroke by up to 40 mm from the 100 mm nominal length, creating a usable travel window of 60 to 100 mm. This stopper sets the end position but does not lock or hold the load without continuous air pressure.
