The AirTAC SAIJ40 Adjustable Cylinder SAIJ40X100-40S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø40mm bore and 100mm stroke, G1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
The AirTAC SAIJ40X100-40-S is a double-acting, double-rod ISO 15552 profile cylinder equipped with a rear stroke adjuster. It features a 100 mm nominal stroke that can be dialed back by up to 40 mm, creating a highly flexible 60-100 mm usable travel window.
This variant includes a magnet for position sensing and uses a standard carbon steel rod with a PT tapered port thread (G1/4). The rear adjuster acts purely as a mechanical stop to fine-tune the retract distance; it does not lock or hold the load without continuous air pressure. For load-holding requirements, an external pilot-operated check valve or a related SAIL lock cylinder is recommended.
| Model | Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-40S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø40 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | G1/4 |
| Rod thread | M12×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 30 mm |
| Max stroke | Up to 1200 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 528 N | 528 N |
| 0.7 MPa | 739 N | — |
| Max (@1.0 MPa) | 108 kgf | |
Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 40 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Dial in the 60-100 mm travel window during product size changes to set new retract endpoints without physically replacing the cylinder.
Fine-tune the final retract position at commissioning using the rear stopper to perfect part seating or clamping depth.
Adjust the effective stroke on the fly for automated test fixtures that require different travel distances for various components.
Select this adjustable model over a fixed-stroke SAI when your setup requires variable end-stops or frequent product changeovers, allowing you to trim the stroke by up to 40 mm without swapping the cylinder. If your application requires less force, stepping down to a 32 mm bore yields 402 N at 0.5 MPa, while stepping up to a 50 mm bore provides 982 N for heavier loads. Since the 100 mm stroke is relatively short, side-loading is less of a concern, but the 16 mm rod still requires external guidance for lateral loads.
To match this ISO 15552 footprint for a direct replacement, specify a 40 mm bore, 100 mm stroke, 40 mm adjustment range, PT port thread, and the -S magnet option. The SAIJ mounting set includes Basic, FA, LB, TC, FTC, TCM1, and TCM2, omitting FB, CA, CB, and CR options. The integrated magnet works seamlessly with AirTAC CMSE reed and DMSE electronic solid-state sensors housed in the dual-sided extruded aluminum barrel grooves.
Quick checklist
The rear adjuster screw acts as a mechanical stop, allowing you to shorten the 100 mm nominal stroke by up to 40 mm. This provides a usable travel window of 60-100 mm. Note that this stopper only sets the end position; it does not lock or hold the load without live air pressure.
At the maximum 1.0 MPa pressure, it can deliver up to 128 kgf.
