AirTAC SAI Series · ISO 15552 Cylinder

Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-50

The AirTAC SAIJ40 Adjustable Cylinder SAIJ40X100-50 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø40mm bore and 100mm stroke, G1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ40 mm
  • Stroke100 mm
  • Port sizeG1/4
  • Acting typeDouble acting
  • Rod threadM12×1.25
  • CushionAdjustable, 30 mm
$70.48 $77.98Save 9% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SAIJ40 stroke, mounting and version on one page All SAIJ40 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-50

The AirTAC SAIJ40X100-50 is a double-acting, double-rod ISO 15552 profile cylinder featuring a rear-mounted stroke adjuster. It provides a nominal 100mm stroke that can be dialed back by up to 50mm, giving you a 50-100mm usable travel window for precise end-position tuning during commissioning.

This adjustable design eliminates the need to swap cylinders or bolt on external stops when product sizes change. The standard carbon steel rod features an M12x1.25 thread, and the barrel is an extruded aluminum profile with sensor grooves on both sides. It uses a PT tapered port thread and includes adjustable air cushions at both ends to decelerate the load smoothly.

Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-50 Technical Specifications

ModelAirtac SAIJ40 Adjustable Cylinder SAIJ40X100-50
SeriesSAI ISO 15552 profile cylinder
Bore sizeØ40 mm
Stroke100 mm
Acting typeDouble acting
Port sizeG1/4
Rod threadM12×1.25
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 800 mm/s
CushionAdjustable, 30 mm
Max strokeUp to 1200 mm

Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.

Theoretical Output Force (Ø40mm)

PressurePush forcePull force
0.5 MPa528 N528 N
0.7 MPa739 N—
Max (@1.0 MPa)108 kgf

Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-50

SAIISO 15552 profile-barrel cylinder series.
40Bore size in mm.
×100Stroke length in mm.
-SOptional built-in magnet for sensor position sensing.

Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.

Where the Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-50 Is Used

tune

Machine Changeover

Dial in the exact end-stop from 50 to 100mm during product size changeovers without swapping hardware.

precision_manufacturing

Position Calibration

Fine-tune the retract position at commissioning to hit precise locating marks on the assembly line.

conveyor_belt

Variable Diverter

Adjust the stroke length on the fly to accommodate different package sizes on a sorting conveyor.

Is the Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-50 the Right Cylinder?

The rear adjuster acts purely as a travel stop and does not hold the load without live air; for true load-holding without pressure, consider the SAIL or BSAI series. To match this ISO 15552 replacement, verify the 100mm stroke, 50mm adjustment, PT port, and the reduced SAIJ mounting set (Basic, FA, LB, TC, FTC, TCM1, TCM2).

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/NPT/G)
  • ✓ Magnet (-S) for sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-50 FAQ

The rear adjuster screw lets you shorten the effective travel by up to 50mm from the 100mm nominal stroke, creating a 50-100mm adjustable window. It functions as a mechanical stop and does not lock the load without live air pressure.
