AirTAC SAI Series · ISO 15552 Cylinder

Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-75

The AirTAC SAIJ40 Adjustable Cylinder SAIJ40X100-75 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø40mm bore and 100mm stroke, G1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ40 mm
  • Stroke100 mm
  • Port sizeG1/4
  • Acting typeDouble acting
  • Rod threadM12×1.25
  • CushionAdjustable, 30 mm
$70.48 $77.98Save 9% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SAIJ40 stroke, mounting and version on one page All SAIJ40 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-75

The AirTAC SAIJ40X100-75 is a double-acting ISO 15552 profile cylinder featuring a rear stroke adjuster that allows you to trim the effective travel down from a 100 mm nominal stroke to a precise 25-100 mm window. The PT tapered port threads ensure a tight, reliable pneumatic connection during high-speed cycling up to 800 mm/s.

Because the adjustment mechanism acts as a mechanical stop at the retract end, you can fine-tune end positions at commissioning without adding external stops. The extruded aluminum barrel includes sensor grooves on both sides, ready to accept CMSE reed or DMSE electronic switches if a magnet is added later. It supports a reduced mounting subset of Basic, FA, LB, TC, FTC, TCM1, and TCM2.

Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-75 Technical Specifications

ModelAirtac SAIJ40 Adjustable Cylinder SAIJ40X100-75
SeriesSAI ISO 15552 profile cylinder
Bore sizeØ40 mm
Stroke100 mm
Acting typeDouble acting
Port sizeG1/4
Rod threadM12×1.25
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 800 mm/s
CushionAdjustable, 30 mm
Max strokeUp to 1200 mm

Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.

Theoretical Output Force (Ø40mm)

PressurePush forcePull force
0.5 MPa528 N528 N
0.7 MPa739 N—
Max (@1.0 MPa)108 kgf

Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-75

SAIISO 15552 profile-barrel cylinder series.
40Bore size in mm.
×100Stroke length in mm.
-SOptional built-in magnet for sensor position sensing.

Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.

Where the Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-75 Is Used

tune

Machine Changeovers

Dial in the 25-100 mm travel window during product size transitions without physically replacing the cylinder or adding external stopper blocks.

precision_manufacturing

End-Position Tuning

Fine-tune the retract distance at commissioning to perfect a pick-and-place motion sequence before locking down the setup.

factory

Variable End Stops

Set distinct retract lengths on the fly for automated lines handling multiple product variants using the same pneumatic footprint.

Is the Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-75 the Right Cylinder?

An adjustable stroke is ideal here for product-size changeovers on a line, letting you dial in the exact end-stop without swapping the cylinder. Remember that the rear adjuster is a travel stop, not a lock; this plain SAIJ will not hold a load without live air. For position holding without pressure, consider an SAIL or BSAI cylinder. To match this ISO 15552 replacement, verify the 40 mm bore, 100 mm nominal stroke, 75 mm adjustment, PT port, and mounting style.

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/NPT/G)
  • ✓ Magnet (-S) for sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-75 FAQ

The 75 mm adjustment code lets you shorten the 100 mm nominal stroke, providing a usable travel window of 25 to 100 mm.

No, the rear adjuster acts only as a mechanical travel stop and cannot hold a load without continuous air pressure. For load-holding without live pressure, you would need an SAIL or BSAI cylinder instead.
