The AirTAC SAIJ40 Adjustable Cylinder SAIJ40X100-75S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø40mm bore and 100mm stroke, G1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
By integrating a 75mm adjustment range, this model transforms a fixed 100mm stroke into a highly versatile 25-100mm usable travel window. The extruded aluminum barrel features sensor grooves on both sides, and because this variant includes the -S magnet, it is fully compatible with AirTAC CMSE reed and DMSE electronic solid-state switches for precise end-of-stroke detection.
Unlike fixed-stroke alternatives, this cylinder allows you to fine-tune the retract end-position directly at the machine without swapping components or adding external stops. The 16mm carbon steel rod and M12x1.25 thread provide robust side-load resistance, while the rear adjuster acts purely as a mechanical travel stop and does not hold the load without live air pressure.
| Model | Airtac SAIJ40 Adjustable Cylinder SAIJ40X100-75S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø40 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | G1/4 |
| Rod thread | M12×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 30 mm |
| Max stroke | Up to 1200 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 528 N | 528 N |
| 0.7 MPa | 739 N | — |
| Max (@1.0 MPa) | 108 kgf | |
Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 40 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Dial in the exact end-stop during product size changeovers, utilizing the 25-100mm travel window to switch fixtures without replacing the cylinder.
Fine-tune the retract position at commissioning to perfect a pressing or clamping operation, avoiding the need for external mechanical stops.
Adjust the retract distance of a conveyor sorting arm on the fly to accommodate different package sizes passing down the line.
If your setup demands greater thrust, stepping up to the 50mm bore yields 982N; if less force is needed, the 32mm bore provides 402N. The adjustable stroke is ideal for machine changeovers and product-size variations, saving the cost of stocking multiple fixed-stroke SAI cylinders.
For direct compatibility, match the exact 40mm bore, 100mm nominal stroke, 75mm adjustment, PT tapered port thread, and the -S magnet option. The SAIJ mounting set includes Basic, FA, LB, TC, FTC, TCM1, and TCM2, deliberately omitting FB, CA, CB, and CR. Remember that the rear adjuster and air cushions only decelerate the travel end; for true load-holding without live air, consider an AirTAC SAIL or BSAI cylinder.
Quick checklist
The cylinder has a nominal 100mm stroke, but the 75mm rear adjuster allows you to shorten the effective travel anywhere down to 25mm, creating a 25-100mm usable stroke window.
No, the rear adjuster functions only as a travel stop to set the end position, and the air cushions only decelerate the motion. Neither component locks or holds the load without live air pressure; for true load-holding, an AirTAC SAIL or BSAI cylinder is required.
