The AirTAC SAIJ40 Adjustable Cylinder SAIJ40X1000-40 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø40mm bore and 1000mm stroke, G1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
The AirTAC SAIJ40X1000-40 is a double-acting ISO 15552 profile cylinder featuring a rear-mounted stroke adjuster. With a 1000 mm nominal stroke and a 40 mm adjustment range, it provides a usable travel window of 960 to 1000 mm. This allows you to dial in the exact retract end-position during commissioning without adding external stops.
The extruded aluminum barrel includes sensor grooves on both sides for flexible switch mounting. The rear adjuster acts purely as a mechanical stop to set the travel end and does not hold the load without live air pressure. For applications requiring position holding without continuous air, consider the SAIL or BSAI series. This model uses a PT G1/4 port and operates at speeds between 30 and 800 mm/s.
| Model | Airtac SAIJ40 Adjustable Cylinder SAIJ40X1000-40 |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø40 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | G1/4 |
| Rod thread | M12×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 30 mm |
| Max stroke | Up to 1200 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 528 N | 528 N |
| 0.7 MPa | 739 N | — |
| Max (@1.0 MPa) | 108 kgf | |
Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 40 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Fine-tune the retract position within the 960-1000 mm window during machine commissioning to accommodate varying product dimensions without swapping cylinders.
Quickly adjust the stroke length on packaging or conveying lines when switching to a different package size, reducing downtime significantly.
Use the 40 mm adjustment range to set precise lower limits on extended-stroke assembly stations, ensuring accurate component placement.
The adjustable stroke is ideal for machine setups requiring a variable end-stop or fine-tuning during product changeover, unlike a fixed-stroke SAI cylinder. Because the stroke is 1000 mm, the unsupported piston rod is highly susceptible to side-loading; an external guide rail must be used to prevent premature seal wear and binding. This cylinder is dimensionally interchangeable per ISO 15552 and supports a mounting subset of Basic, FA, LB, TC, FTC, TCM1, and TCM2.
Quick checklist
At the maximum pressure of 1.0 MPa, it delivers up to 128 kgf.
A rear mechanical screw allows you to trim the effective travel back by up to 40 mm, creating a usable stroke window of 960 to 1000 mm. The adjuster functions as a travel stop and does not lock or hold the load without live air pressure.
