Airtac SAIJ40 Adjustable Cylinder SAIJ40X1000-75
The AirTAC Airtac SAIJ40 Adjustable Cylinder SAIJ40X1000-75 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø40mm bore and 1000mm stroke, G1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ40 mm
- Stroke1000 mm
- Port sizeG1/4
- Acting typeDouble acting
- Rod threadM12×1.25
- CushionAdjustable, 30 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAIJ40 Adjustable Cylinder SAIJ40X1000-75
The AirTAC SAIJ40X1000-75 is a double-acting ISO 15552 profile cylinder featuring a rear stroke adjuster. It provides a 925-1000mm usable travel window, letting you dial back the nominal 1000mm stroke by up to 75mm during commissioning. Delivering 628N of push force at 0.5MPa, it uses a G1/4 port and a 16mm carbon steel rod.
This extruded aluminum profile cylinder includes sensor grooves on both sides and variable air cushions at both ends. The rear stopper acts purely as a travel end deceleration device, not a lock, so it cannot hold a load without live air pressure.
Airtac SAIJ40 Adjustable Cylinder SAIJ40X1000-75 Technical Specifications
| Model | Airtac SAIJ40 Adjustable Cylinder SAIJ40X1000-75 |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø40 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | G1/4 |
| Rod thread | M12×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 30 mm |
| Max stroke | Up to 1200 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø40mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 628 N | 528 N |
| 0.7 MPa | 880 N | — |
| Max (@1.0 MPa) | 128 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAIJ40 Adjustable Cylinder SAIJ40X1000-75
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 40 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAIJ40 Adjustable Cylinder SAIJ40X1000-75 Is Used
Machine Changeover
Quickly reconfigure the 925-1000mm travel window for different product lengths on the same line without changing the physical cylinder setup.
End-Position Tuning
Fine-tune the exact retracted position during commissioning to dial in precise mechanical stops for long-stroke automated processes.
Material Handling
Drive long-travel pushers or diverters where the 628N force at 0.5MPa is sufficient, but the final stopping point requires on-site adjustment.
Is the Airtac SAIJ40 Adjustable Cylinder SAIJ40X1000-75 the Right Cylinder?
Choose this 40mm bore when you need more force than a 32mm cylinder (402N push at 0.5MPa) but want a smaller footprint than a 50mm option (982N). The adjustable stroke is ideal for product changeovers, allowing you to fine-tune the end position without swapping the cylinder or bolting on external stops. For a fixed end position, a standard SAI cylinder is simpler.
Because this is a 1000mm stroke, the 16mm rod needs external guidance to prevent excessive side-loading. To match this ISO 15552 replacement exactly, specify the 40mm bore, 1000mm stroke, 75mm adjustment, PT port thread, and your required mounting from the SAIJ set (Basic, FA, LB, TC, FTC, TCM1, TCM2). No magnet is included, so position sensing is not supported.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAIJ40 Adjustable Cylinder SAIJ40X1000-75 FAQ
At 0.5MPa operating pressure, this 40mm bore cylinder provides 628N of push force and 528N of pull force. At 0.7MPa, the push force increases to 879N.
The rear adjuster screw lets you shorten the effective stroke by up to 75mm, creating a 925-1000mm travel window. It acts as a mechanical stop to set the end position and does not lock the load without air pressure.
