Airtac SAIJ80 Adjustable Cylinder SAIJ80BX1000-30
The AirTAC SAIJ80 Adjustable Cylinder SAIJ80BX1000-30 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø80mm bore and 1000mm stroke, G3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ80 mm
- Stroke1000 mm
- Port sizeG3/8
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 36 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAIJ80 Adjustable Cylinder SAIJ80BX1000-30
The AirTAC SAIJ80X1000-30 is a double-acting ISO 15552 profile cylinder featuring a rear stroke adjuster. It provides a 970 to 1000 mm usable travel window by dialing back the nominal 1000 mm stroke up to 30 mm via the external stopper screw. This 80 mm bore generates 2513 N of pull force at 0.5 MPa and 4523 N at 0.9 MPa, making it a robust choice for heavy-duty positioning.
Built with a SUS304 stainless steel rod and PT tapered ports, this unit omits the FB, CA, CB and CR mounting options, supporting only the Basic, FA, LB, TC, FTC, TCM1 and TCM2 interfaces. The extruded aluminum barrel includes sensor grooves on both sides, though this specific SKU is configured without a magnet for position sensing.
Airtac SAIJ80 Adjustable Cylinder SAIJ80BX1000-30 Technical Specifications
| Model | Airtac SAIJ80 Adjustable Cylinder SAIJ80BX1000-30 |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø80 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | G3/8 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø80mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 2268 N | 2268 N |
| 0.7 MPa | 3175 N | — |
| Max (@1.0 MPa) | 463 kgf | |
Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAIJ80 Adjustable Cylinder SAIJ80BX1000-30
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 80 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAIJ80 Adjustable Cylinder SAIJ80BX1000-30 Is Used
Machine Changeover
Dial in the exact 970 to 1000 mm end position during product size changes on a packaging line without physically swapping the cylinder.
Assembly Line Tuning
Fine-tune the retract position during commissioning to align large parts perfectly, avoiding the cost of custom machined spacers.
Is the Airtac SAIJ80 Adjustable Cylinder SAIJ80BX1000-30 the Right Cylinder?
Select this 80 mm bore when an application requires substantial thrust but demands fine-tuning of the end position during commissioning without adding external stops. If you need less force, stepping down to a 63 mm bore yields 1402 N of pull at 0.5 MPa. Because this model features a 1000 mm stroke, the 25 mm rod diameter and M20x1.5 thread carry significant side loads, so an external guide is strongly recommended to prevent rod binding.
The rear adjuster acts purely as a travel stop and does not hold the load without live air pressure. For load-holding requirements without continuous air, consider the SAIL pneumatic lock or BSAI clamp-lock series. This cylinder is dimensionally interchangeable per ISO 15552 and uses a PT port thread.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAIJ80 Adjustable Cylinder SAIJ80BX1000-30 FAQ
At 0.9 MPa the push force increases to 4523 N.
The rear adjuster screw lets you shorten the effective travel from 1000 mm down to 970 mm. It functions as a mechanical stop to fine-tune the retract position and is not a lock that holds the load without air pressure.
