Airtac SC100 Standard Cylinder SC100X1000CB
The AirTAC Airtac SC100 Standard Cylinder SC100X1000CB is a genuine double-acting standard air cylinder with a Ø100mm bore and 1000mm stroke, PT1/2 air ports and adjustable end cushioning. It is used for push, pull, lift and clamp motion in industrial automation.
- BoreØ100 mm
- Stroke1000 mm
- Port sizePT1/2
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 29 mm
About the Airtac SC100 Standard Cylinder SC100X1000CB
The SC100X1000CB is a double-acting pneumatic cylinder delivering 3927 N of push force at 0.5 MPa and up to 7068 N at the maximum operating pressure of 0.9 MPa. With a 100 mm bore and a long 1000 mm stroke, it is built for applications requiring substantial linear force over an extended travel distance.
This model features a 25 mm diameter piston rod and a 29 mm adjustable air cushion at each end to decelerate the piston smoothly. The CB suffix denotes a rear double clevis mount (fork), using accessory F-SC100CB, which allows the cylinder body to pivot during operation. The body length A is 188 mm, giving a total extended length of approximately 1188 mm.
Airtac SC100 Standard Cylinder SC100X1000CB Technical Specifications
| Model | Airtac SC100 Standard Cylinder SC100X1000CB |
|---|---|
| Series | SC standard tie-rod cylinder |
| Bore size | Ø100 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | PT1/2 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 29 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SC series datasheet. Operating pressure 0.15–1.0 MPa, proof pressure 1.5 MPa, temperature −20 to +70 °C. Confirm against the product label before installation. Thread options: PT (standard) / G.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3682 N |
| 0.7 MPa | 5498 N | — |
| Max (approx.) | 801 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SC100 Standard Cylinder SC100X1000CB
| SC | Standard tie-rod cylinder series. |
|---|---|
| 100 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related variants: SCD (double rod), SCJ (adjustable stroke), SCT (multi-position). Seals: TPU standard / H = Viton / N = NBR. Thread: blank = PT, G = G thread.
Where the Airtac SC100 Standard Cylinder SC100X1000CB Is Used
Heavy Part Ejection
Provides the 3927 N push force needed to eject large plastic or metal parts from molds and forming dies over a 1000 mm stroke.
Pallet Transfer
Moves heavy pallets or bins across roller conveyors in distribution centers, with the CB clevis allowing the cylinder to pivot as it pushes.
Damper Actuation
Operates large ventilation or process dampers in industrial plants, using the long stroke for full-open to full-close modulation.
Is the Airtac SC100 Standard Cylinder SC100X1000CB the Right Cylinder?
Choose the SC100 bore when your application needs around 3927 N of force at standard shop air. If your load is lighter, stepping down to an SC80 bore saves space and air while still providing 2513 N at 0.5 MPa. For higher force demands, the SC125 bore offers 6136 N at the same pressure.
At a 1000 mm stroke, the unsupported rod is long and susceptible to bending under side loads. Always guide the load externally or use a guided cylinder if any radial force is present. For direct replacement, match five points: 100 mm bore, 1000 mm stroke, PT port thread, rear double clevis (CB) mounting, and the absence of a magnet.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SC100 Standard Cylinder SC100X1000CB FAQ
At 0.5 MPa, the push force is 3927 N and the pull force is 3681 N. At the maximum operating pressure of 0.9 MPa, the push force reaches 7068 N.
No. The SC100 is a double-acting cylinder and does not hold position without live air pressure. If the load must be held when pressure is lost or the valve is centered, you must add a pilot-operated check valve or an external mechanical rod lock.
