Airtac SC100 Standard Cylinder SC100X1000STC
The AirTAC Airtac SC100 Standard Cylinder SC100X1000STC is a genuine double-acting standard air cylinder with a Ø100mm bore and 1000mm stroke, PT1/2 air ports and adjustable end cushioning. It is used for push, pull, lift and clamp motion in industrial automation.
- BoreØ100 mm
- Stroke1000 mm
- Port sizePT1/2
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 29 mm
About the Airtac SC100 Standard Cylinder SC100X1000STC
The AirTAC SC100X1000STC is a double-acting tie-rod cylinder delivering 3927 N of push force at 0.5 MPa (7068 N at 0.9 MPa). With a 100 mm bore and 1000 mm stroke, this model is built for long linear movements in industrial automation. The 25 mm diameter piston rod and 29 mm adjustable air cushion provide smooth deceleration at stroke ends.
This unit includes a built-in magnet (-S suffix) for direct mounting of CMSG/DMSG/EMSG sensors, plus a centre trunnion mount (TC suffix) with the TCM1 bracket for pivoting applications. The body length A is 188 mm, giving a total extended length of approximately 1188 mm. Operating pressure ranges from 0.15 to 1.0 MPa with filtered air.
Airtac SC100 Standard Cylinder SC100X1000STC Technical Specifications
| Model | Airtac SC100 Standard Cylinder SC100X1000STC |
|---|---|
| Series | SC standard tie-rod cylinder |
| Bore size | Ø100 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | PT1/2 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 29 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SC series datasheet. Operating pressure 0.15–1.0 MPa, proof pressure 1.5 MPa, temperature −20 to +70 °C. Confirm against the product label before installation. Thread options: PT (standard) / G.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3682 N |
| 0.7 MPa | 5498 N | — |
| Max (approx.) | 801 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SC100 Standard Cylinder SC100X1000STC
| SC | Standard tie-rod cylinder series. |
|---|---|
| 100 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related variants: SCD (double rod), SCJ (adjustable stroke), SCT (multi-position). Seals: TPU standard / H = Viton / N = NBR. Thread: blank = PT, G = G thread.
Where the Airtac SC100 Standard Cylinder SC100X1000STC Is Used
Long-Stroke Material Transfer
Pushes or pulls heavy pallets and components across 1-metre transfer stations, with trunnion mounting allowing the cylinder to pivot as the load moves.
Automated Welding Fixtures
Positions large weldments and clamping arms in automotive jigs. The built-in magnet confirms full extension and retraction via reed sensors.
Heavy-Duty Gate Actuation
Operates sliding or swinging safety gates and hopper doors on bulk handling equipment, leveraging the centre trunnion for smooth angular motion.
Is the Airtac SC100 Standard Cylinder SC100X1000STC the Right Cylinder?
Choose the SC100 bore when your application needs around 3927 N of force at 0.5 MPa. If you require less force, the SC80 bore provides 2513 N at the same pressure. For heavier loads, step up to the SC125 bore offering 6136 N. Always match replacement cylinders across five key points: bore, stroke, port thread (PT), mounting accessory (F-SC100TC), and magnet option (-S).
At 1000 mm stroke, the piston rod is fully extended well beyond the body. Avoid side loading on the unsupported rod—use external linear guides or a guided cylinder configuration to prevent rod bending and premature bearing wear.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SC100 Standard Cylinder SC100X1000STC FAQ
At 0.7 MPa operating pressure, the push force is 5497 N. The maximum push force at 0.9 MPa is 7068 N, and the theoretical force at 1.0 MPa is 801 kgf.
No. The SC series is a tie-rod cylinder that is physically shorter than an ISO 15552 profile cylinder, so it is not dimensionally interchangeable. Replace it with another AirTAC SC100 tie-rod cylinder matching the 1000 mm stroke, PT port, TC centre trunnion mount, and magnet sensor option.
