Airtac SC80 Standard Cylinder SC80X10
The AirTAC Airtac SC80 Standard Cylinder SC80X10 is a genuine double-acting standard air cylinder with a Ø80mm bore and 10mm stroke, PT3/8 air ports and adjustable end cushioning. It is used for push, pull, lift and clamp motion in industrial automation.
- BoreØ80 mm
- Stroke10 mm
- Port sizePT3/8
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 28 mm
About the Airtac SC80 Standard Cylinder SC80X10
The AirTAC SC80X10 is a double-acting tie-rod cylinder delivering a compact 10 mm stroke from an 80 mm bore. At 0.5 MPa it generates 2513 N of push force, making it suitable for short-throw clamping or ejection tasks where a large force must be applied over a minimal distance.
This model features a 25 mm diameter piston rod with M20x1.5 threads and PT3/8 ports. The adjustable pneumatic cushion (28 mm length) decelerates the piston at end of stroke to reduce impact noise. Total extended body length is approximately 192 mm (body length A of 182 mm plus 10 mm stroke).
Airtac SC80 Standard Cylinder SC80X10 Technical Specifications
| Model | Airtac SC80 Standard Cylinder SC80X10 |
|---|---|
| Series | SC standard tie-rod cylinder |
| Bore size | Ø80 mm |
| Stroke | 10 mm |
| Acting type | Double acting |
| Port size | PT3/8 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 28 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SC series datasheet. Operating pressure 0.15–1.0 MPa, proof pressure 1.5 MPa, temperature −20 to +70 °C. Confirm against the product label before installation. Thread options: PT (standard) / G.
Theoretical Output Force (Ø80mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 2513 N | 2268 N |
| 0.7 MPa | 3519 N | — |
| Max (approx.) | 513 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SC80 Standard Cylinder SC80X10
| SC | Standard tie-rod cylinder series. |
|---|---|
| 80 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related variants: SCD (double rod), SCJ (adjustable stroke), SCT (multi-position). Seals: TPU standard / H = Viton / N = NBR. Thread: blank = PT, G = G thread.
Where the Airtac SC80 Standard Cylinder SC80X10 Is Used
Short-Stroke Clamping
Applies 2513 N at 0.5 MPa to hold workpieces securely during machining or assembly, with only 10 mm of linear travel to minimize cycle time.
Part Ejection
Delivers a powerful, controlled push to eject parts from a die or fixture, using the adjustable cushion to soften the impact at the end of the short stroke.
Diverter Gate Actuation
Operates a small diverter gate or stop on a conveyor line, where the high force capacity ensures reliable actuation even with heavy product back-pressure.
Is the Airtac SC80 Standard Cylinder SC80X10 the Right Cylinder?
Choose the SC80 bore when your application needs roughly 2500 N of push force at standard plant pressure. If you need less force in a similar compact envelope, stepping down to the SC63 bore (1559 N at 0.5 MPa) can reduce air consumption. For higher force, the SC100 bore provides 3927 N at the same pressure.
This 10 mm stroke is a standard offering and well within the 1500 mm maximum for the 80 mm bore. When replacing an existing cylinder, match five points: 80 mm bore, 10 mm stroke, PT3/8 port thread, basic mounting (no bracket), and confirm whether a magnet (-S) is required for sensors.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SC80 Standard Cylinder SC80X10 FAQ
At 0.7 MPa, the SC80X10 produces 3518 N of push force. The maximum operating force at 0.9 MPa is 4523 N. The theoretical force at 1.0 MPa is 513 kgf.
This basic model SC80X10 does not include a mounting bracket. You can order the centre trunnion kit separately (part code F-SC80TC, which includes the TCM1 bracket) and attach it to the tie-rod assembly for pivoting applications.
