Airtac SC80 Standard Cylinder SC80X100
The AirTAC Airtac SC80 Standard Cylinder SC80X100 is a genuine double-acting standard air cylinder with a Ø80mm bore and 100mm stroke, PT3/8 air ports and adjustable end cushioning. It is used for push, pull, lift and clamp motion in industrial automation.
- BoreØ80 mm
- Stroke100 mm
- Port sizePT3/8
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 28 mm
About the Airtac SC80 Standard Cylinder SC80X100
The AirTAC SC80X100 is a double-acting tie-rod cylinder delivering 2513 N of push force at 0.5 MPa (4523 N at the maximum operating pressure of 0.9 MPa). With an 80 mm bore and a 100 mm standard stroke, it features a 25 mm piston rod and a 28 mm adjustable air cushion at each end to decelerate the load smoothly.
This model uses a PT1/4 port and an M20x1.5 rod thread. The body length A is 182 mm, giving a compact footprint for a cylinder in this force class. It is a genuine AirTAC SC series unit built for reliable industrial automation with filtered air.
Airtac SC80 Standard Cylinder SC80X100 Technical Specifications
| Model | Airtac SC80 Standard Cylinder SC80X100 |
|---|---|
| Series | SC standard tie-rod cylinder |
| Bore size | Ø80 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | PT3/8 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 28 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SC series datasheet. Operating pressure 0.15–1.0 MPa, proof pressure 1.5 MPa, temperature −20 to +70 °C. Confirm against the product label before installation. Thread options: PT (standard) / G.
Theoretical Output Force (Ø80mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 2513 N | 2268 N |
| 0.7 MPa | 3519 N | — |
| Max (approx.) | 513 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SC80 Standard Cylinder SC80X100
| SC | Standard tie-rod cylinder series. |
|---|---|
| 80 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related variants: SCD (double rod), SCJ (adjustable stroke), SCT (multi-position). Seals: TPU standard / H = Viton / N = NBR. Thread: blank = PT, G = G thread.
Where the Airtac SC80 Standard Cylinder SC80X100 Is Used
Package Sorting Gates
The 100 mm stroke and 2513 N push force at 0.5 MPa reliably actuate diverter gates on medium-speed package handling lines, directing cartons between conveyor lanes.
Clamping & Fixturing
Provides stable, high-force clamping for woodworking or metal fabrication jigs. The adjustable cushion reduces vibration at the end of the 100 mm stroke, protecting the fixture and workpiece.
Press & Assembly Tools
Delivers up to 4523 N at 0.9 MPa for light press-fit assembly, riveting, or punching operations where a compact, tie-rod cylinder is preferred.
Is the Airtac SC80 Standard Cylinder SC80X100 the Right Cylinder?
Select the SC80X100 when your application needs roughly 2500 N of force at standard plant pressure. If you require less force, the SC63 series provides 1559 N at 0.5 MPa, allowing a smaller, lighter actuator. For higher force, the SC100 series steps up to 3927 N at the same pressure.
To replace an existing cylinder, match five points exactly: 80 mm bore, 100 mm stroke, PT port thread, basic (no mounting accessory) configuration, and the absence of a magnet. The SC is a tie-rod cylinder and is not dimensionally interchangeable with ISO 15552 profile cylinders.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SC80 Standard Cylinder SC80X100 FAQ
At 0.5 MPa, the push force is 2513 N and the pull force is 2268 N. At the maximum operating pressure of 0.9 MPa, the push force reaches 4523 N. The theoretical maximum force at 1.0 MPa is 513 kgf.
No. The SC series is a tie-rod cylinder with a different body length and mounting dimensions than an ISO 15552 profile cylinder. It is a direct replacement only for another AirTAC SC80 cylinder with the same bore, stroke, and port thread.
