Airtac SC80 Standard Cylinder SC80X1000
The AirTAC Airtac SC80 Standard Cylinder SC80X1000 is a genuine double-acting standard air cylinder with a Ø80mm bore and 1000mm stroke, PT3/8 air ports and adjustable end cushioning. It is used for push, pull, lift and clamp motion in industrial automation.
- BoreØ80 mm
- Stroke1000 mm
- Port sizePT3/8
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 28 mm
About the Airtac SC80 Standard Cylinder SC80X1000
The AirTAC SC80X1000 is a double-acting tie-rod cylinder delivering 2513 N of push force at 0.5 MPa and up to 4523 N at 0.9 MPa, making it a robust linear actuator for long-travel applications. Its 25 mm diameter piston rod and 28 mm adjustable air cushion provide reliable end-of-stroke deceleration across the full 1000 mm stroke.
With a compact body length A of 182 mm and PT3/8 ports, this genuine AirTAC cylinder is designed for filtered air systems operating between 0.15 and 1.0 MPa. The standard TPU seals offer a temperature range of -20 to +70 °C, suitable for general industrial automation tasks requiring a 1000 mm linear movement.
Airtac SC80 Standard Cylinder SC80X1000 Technical Specifications
| Model | Airtac SC80 Standard Cylinder SC80X1000 |
|---|---|
| Series | SC standard tie-rod cylinder |
| Bore size | Ø80 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | PT3/8 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 28 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SC series datasheet. Operating pressure 0.15–1.0 MPa, proof pressure 1.5 MPa, temperature −20 to +70 °C. Confirm against the product label before installation. Thread options: PT (standard) / G.
Theoretical Output Force (Ø80mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 2513 N | 2268 N |
| 0.7 MPa | 3519 N | — |
| Max (approx.) | 513 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SC80 Standard Cylinder SC80X1000
| SC | Standard tie-rod cylinder series. |
|---|---|
| 80 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related variants: SCD (double rod), SCJ (adjustable stroke), SCT (multi-position). Seals: TPU standard / H = Viton / N = NBR. Thread: blank = PT, G = G thread.
Where the Airtac SC80 Standard Cylinder SC80X1000 Is Used
Long-Reach Material Transfer
Pushes or pulls heavy bins and pallets across 1-meter wide conveyor transfer stations, using its 2513 N force at 0.5 MPa to move loads reliably.
Panel Laminating Presses
Provides the 1000 mm closing stroke for large-format wood or composite panel presses, with adjustable cushioning to prevent impact damage on sensitive surfaces.
Automated Sorting Gates
Actuates tall diverter gates in logistics sortation systems, leveraging the full meter of travel to redirect high-volume parcel flows between chutes.
Is the Airtac SC80 Standard Cylinder SC80X1000 the Right Cylinder?
Choose the SC80 bore when your application requires a force class around 2513 N at 0.5 MPa. If you need more force, stepping up to the SC100 bore provides 3927 N at the same pressure; for a lighter, more compact solution, the SC63 bore delivers 1559 N. This 1000 mm stroke is within the standard 1500 mm maximum for the 80 mm bore.
For a stroke of this length, side loading is a critical consideration. The unsupported 25 mm rod can bend under lateral forces, so always use an external linear guide or rod support to absorb side loads. When replacing an existing cylinder, ensure a perfect 5-point match: 80 mm bore, 1000 mm stroke, PT3/8 thread, basic mounting, and no magnet.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SC80 Standard Cylinder SC80X1000 FAQ
At the standard 0.5 MPa operating pressure, the push force is 2513 N and the pull force is 2268 N. At the maximum operating pressure of 0.9 MPa, the push force increases to 4523 N. The theoretical maximum force at 1.0 MPa is 513 kgf.
A 1000 mm stroke with a 25 mm rod is susceptible to buckling under compressive loads and bending from side forces. You must guide the load externally with a linear rail or rod support. The cylinder itself should only handle axial push/pull forces; any lateral load must be absorbed by the external guide system.
