Airtac SC80 Standard Cylinder SC80X1000N
The AirTAC Airtac SC80 Standard Cylinder SC80X1000N is a genuine double-acting standard air cylinder with a Ø80mm bore and 1000mm stroke, PT3/8 air ports and adjustable end cushioning. It is used for push, pull, lift and clamp motion in industrial automation.
- BoreØ80 mm
- Stroke1000 mm
- Port sizePT3/8
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 28 mm
About the Airtac SC80 Standard Cylinder SC80X1000N
The AirTAC SC80X1000N is an 80 mm bore double-acting tie-rod cylinder supplying 2513 N of push force and 2268 N of pull force at 0.5 MPa. Its 1000 mm stroke is within the standard offering for this bore, and the 25 mm diameter piston rod provides substantial rigidity for linear movements.
This model is fitted with NBR (nitrile) seals, making it a cost-effective choice for general industrial environments within the standard -20 to +70 °C temperature range. The adjustable air cushion at each end, with a 28 mm cushion length, decelerates the piston smoothly to reduce end-of-stroke impact, while the PT1/4 port threads ensure straightforward pneumatic connections.
Airtac SC80 Standard Cylinder SC80X1000N Technical Specifications
| Model | Airtac SC80 Standard Cylinder SC80X1000N |
|---|---|
| Series | SC standard tie-rod cylinder |
| Bore size | Ø80 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | PT3/8 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 28 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SC series datasheet. Operating pressure 0.15–1.0 MPa, proof pressure 1.5 MPa, temperature −20 to +70 °C. Confirm against the product label before installation. Thread options: PT (standard) / G.
Theoretical Output Force (Ø80mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 2513 N | 2268 N |
| 0.7 MPa | 3519 N | — |
| Max (approx.) | 513 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SC80 Standard Cylinder SC80X1000N
| SC | Standard tie-rod cylinder series. |
|---|---|
| 80 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related variants: SCD (double rod), SCJ (adjustable stroke), SCT (multi-position). Seals: TPU standard / H = Viton / N = NBR. Thread: blank = PT, G = G thread.
Where the Airtac SC80 Standard Cylinder SC80X1000N Is Used
Material Handling Gates
The 1000 mm stroke and 2513 N push force at 0.5 MPa operate long-travel diverter gates on wide conveyor systems, sorting large packages or pallets between multiple lanes.
Woodworking Clamp Carriages
Positions heavy saw or router carriages over a full meter of travel. The 25 mm rod and tie-rod construction handle the repetitive forces of edge-banding and panel-sizing operations.
Grain Silo Slide Gates
Actuates large slide gates at the base of silos or hoppers. The NBR seals are compatible with the dusty, ambient-temperature conditions found in grain handling facilities.
Is the Airtac SC80 Standard Cylinder SC80X1000N the Right Cylinder?
Step up to a 100 mm bore (3927 N at 0.5 MPa) if your application demands higher force, or down to a 63 mm bore (1559 N at 0.5 MPa) for a more compact footprint. For this 1000 mm stroke, side loads must be managed carefully; the long, unsupported 25 mm rod can bend under lateral force. Use an external linear guide or a guided cylinder to absorb side loads and protect the rod bearing from premature wear. When replacing, match five key points: 80 mm bore, 1000 mm stroke, PT port thread, NBR seal material, and the basic (no bracket) mounting configuration.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SC80 Standard Cylinder SC80X1000N FAQ
At 0.7 MPa operating pressure, the SC80X1000N generates 3518 N of push force and approximately 3175 N of pull force (calculated from the 2268 N pull force at 0.5 MPa). The maximum push force at 0.9 MPa is 4523 N.
No. The NBR seals in this SC80X1000N model are rated for an operating temperature range of -20 to +70 °C. For high-temperature environments up to 150 °C, you would need the 'H' suffix variant (SC80X1000H) which is equipped with Viton (FKM) seals.
