Airtac SC80 Standard Cylinder SC80X1000S
The AirTAC Airtac SC80 Standard Cylinder SC80X1000S is a genuine double-acting standard air cylinder with a Ø80mm bore and 1000mm stroke, PT3/8 air ports and adjustable end cushioning. It is used for push, pull, lift and clamp motion in industrial automation.
- BoreØ80 mm
- Stroke1000 mm
- Port sizePT3/8
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 28 mm
About the Airtac SC80 Standard Cylinder SC80X1000S
The AirTAC SC80X1000S is a double-acting pneumatic cylinder delivering 2513 N of push force at 0.5 MPa and up to 4523 N at 0.9 MPa operating pressure. With an 80 mm bore and a 1000 mm stroke, this model features a 25 mm diameter piston rod and a 28 mm adjustable air cushion at each end to decelerate the load smoothly.
This variant includes the factory-installed -S magnet, allowing CMSG, DMSG, or EMSG reed and solid-state sensors to clamp directly onto the tie-rod barrel for contactless position sensing. The body length A is 182 mm, giving a total extended length of approximately 1182 mm, and the PT1/8 port supplies filtered air at 0.15–1.0 MPa.
Airtac SC80 Standard Cylinder SC80X1000S Technical Specifications
| Model | Airtac SC80 Standard Cylinder SC80X1000S |
|---|---|
| Series | SC standard tie-rod cylinder |
| Bore size | Ø80 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | PT3/8 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 28 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SC series datasheet. Operating pressure 0.15–1.0 MPa, proof pressure 1.5 MPa, temperature −20 to +70 °C. Confirm against the product label before installation. Thread options: PT (standard) / G.
Theoretical Output Force (Ø80mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 2513 N | 2268 N |
| 0.7 MPa | 3519 N | — |
| Max (approx.) | 513 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SC80 Standard Cylinder SC80X1000S
| SC | Standard tie-rod cylinder series. |
|---|---|
| 80 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related variants: SCD (double rod), SCJ (adjustable stroke), SCT (multi-position). Seals: TPU standard / H = Viton / N = NBR. Thread: blank = PT, G = G thread.
Where the Airtac SC80 Standard Cylinder SC80X1000S Is Used
Long-Reach Material Transfer
The 1000 mm stroke pushes or pulls large panels, cartons, or bins across wide conveyor gaps, with the built-in magnet confirming end-of-stroke position.
Automated Welding Fixtures
Clamps and positions heavy weldments with 2513 N of force. The -S magnet enables sensor feedback to the PLC for interlocked cycle start.
Sawmill Log Stops
Deploys a robust stop gate into a log chain. The 28 mm cushion absorbs impact energy, and the magnet signals gate-open status to the control system.
Is the Airtac SC80 Standard Cylinder SC80X1000S the Right Cylinder?
For applications needing more force, step up to the 100 mm bore SC100 series, which provides 3927 N at 0.5 MPa. If a shorter, more compact cylinder is acceptable, the 63 mm bore SC63 series offers 1559 N at the same pressure. At a 1000 mm stroke, the 25 mm rod is subject to bending under side loads; always guide the load externally or use a guided cylinder if off-axis forces are present. When replacing this cylinder, match five points: 80 mm bore, 1000 mm stroke, PT1/8 port thread, the -S magnet for sensor compatibility, and the basic (no bracket) mounting configuration.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SC80 Standard Cylinder SC80X1000S FAQ
At 0.5 MPa, the push force is 2513 N and the pull force is 2268 N. At the maximum operating pressure of 0.9 MPa, the push force reaches 4523 N. The theoretical maximum at 1.0 MPa is 513 kgf.
Yes. The -S suffix indicates a built-in magnet inside the piston. This allows AirTAC CMSG (reed) or DMSG/EMSG (solid-state) sensors to be mounted directly on the cylinder's tie-rods to detect piston position without external flags.
