Airtac SC80 Standard Cylinder SC80X1000TC
The AirTAC Airtac SC80 Standard Cylinder SC80X1000TC is a genuine double-acting standard air cylinder with a Ø80mm bore and 1000mm stroke, PT3/8 air ports and adjustable end cushioning. It is used for push, pull, lift and clamp motion in industrial automation.
- BoreØ80 mm
- Stroke1000 mm
- Port sizePT3/8
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 28 mm
About the Airtac SC80 Standard Cylinder SC80X1000TC
The AirTAC SC80X1000TC is a double-acting tie-rod cylinder delivering 2513 N of push force at 0.5 MPa and up to 4523 N at the maximum operating pressure of 0.9 MPa. With an 80 mm bore and a 1000 mm stroke, it uses a 25 mm diameter piston rod and PT3/8 ports, making it a robust choice for long linear movements.
This model features a centre trunnion (TC) mount, supplied with the TCM1 bracket (F-SC80TC), allowing the cylinder to pivot during operation. The adjustable air cushion (28 mm) decelerates the piston smoothly at the end of the 1000 mm stroke, reducing impact and noise in high-cycle applications.
Airtac SC80 Standard Cylinder SC80X1000TC Technical Specifications
| Model | Airtac SC80 Standard Cylinder SC80X1000TC |
|---|---|
| Series | SC standard tie-rod cylinder |
| Bore size | Ø80 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | PT3/8 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 28 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SC series datasheet. Operating pressure 0.15–1.0 MPa, proof pressure 1.5 MPa, temperature −20 to +70 °C. Confirm against the product label before installation. Thread options: PT (standard) / G.
Theoretical Output Force (Ø80mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 2513 N | 2268 N |
| 0.7 MPa | 3519 N | — |
| Max (approx.) | 513 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SC80 Standard Cylinder SC80X1000TC
| SC | Standard tie-rod cylinder series. |
|---|---|
| 80 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related variants: SCD (double rod), SCJ (adjustable stroke), SCT (multi-position). Seals: TPU standard / H = Viton / N = NBR. Thread: blank = PT, G = G thread.
Where the Airtac SC80 Standard Cylinder SC80X1000TC Is Used
Long-Stroke Material Transfer
The 1000 mm stroke and 2513 N push force at 0.5 MPa efficiently transfer heavy parts between distant conveyor stations, with the trunnion mount absorbing any misalignment.
Pivoting Clamp Actuation
The centre trunnion (TC) mount allows the cylinder body to pivot, making it ideal for operating large swing clamps or welding fixtures that require a long reach.
Pallet Dispenser Pusher
Delivers the sustained force needed to push a full stack of pallets into a dispenser magazine, with the 28 mm cushion softening the end-of-stroke impact.
Is the Airtac SC80 Standard Cylinder SC80X1000TC the Right Cylinder?
Select the SC80 when your application requires between 2513 N and 4523 N of force. If your load is lighter, stepping down to the SC63 bore (1559 N at 0.5 MPa) can reduce air consumption. For higher force demands, the SC100 bore provides 3927 N at the same 0.5 MPa pressure.
For this 1000 mm stroke, carefully evaluate side loads. A long, unsupported 25 mm rod is susceptible to bending under lateral force. Use an external guide rail or a guided cylinder to protect the rod bearing and ensure linear motion. When replacing an existing unit, match the 80 mm bore, 1000 mm stroke, PT3/8 port thread, centre trunnion (TC) mount, and confirm if a magnet (-S) is needed for sensors.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SC80 Standard Cylinder SC80X1000TC FAQ
At 0.5 MPa, the push force is 2513 N and the pull force is 2268 N. At the maximum operating pressure of 0.9 MPa, the push force increases to 4523 N. The theoretical maximum force at 1.0 MPa is 513 kgf.
No. The AirTAC SC series is a tie-rod cylinder that is shorter than a standard ISO 15552 profile cylinder, so it is not dimensionally interchangeable. It replaces another AirTAC SC80 cylinder with the same bore, stroke, PT port thread, and TC mount.
