Airtac SCT32-63 Multi-Position Tandem Air Cylinder SCT32X110X110
The AirTAC Airtac SCT32-63 Multi-Position Tandem Air Cylinder SCT32X110X110 is a genuine double-acting MULTI-POSITION (tandem) air cylinder: two piston sections of 110mm and 110mm give 3 controllable stop positions across a 220mm total travel, with a Ø32mm bore, PT1/8 ports and adjustable end cushioning.
- BoreØ32 mm
- Stroke 1110 mm
- Stroke 2110 mm
- Total travel220 mm
- Positions3 stops
- Port sizePT1/8
About the Airtac SCT32-63 Multi-Position Tandem Air Cylinder SCT32X110X110
The SCT32X110X110 is a tandem multi-position cylinder that delivers three fixed rod positions: fully retracted (0 mm), an intermediate stop at 110 mm, and full extension at 220 mm. Each piston section generates 402 N of push force at 0.5 MPa, making it suitable for light sorting or diverting tasks where space is limited.
This 32 mm bore model uses a 12 mm diameter rod and PT1/8 ports. The tie-rod body has a base length of 233 mm, and the adjustable air cushion on each section is 21 mm long, helping to manage end-of-stroke impact at the discrete stops.
Airtac SCT32-63 Multi-Position Tandem Air Cylinder SCT32X110X110 Technical Specifications
| Model | Airtac SCT32-63 Multi-Position Tandem Air Cylinder SCT32X110X110 |
|---|---|
| Series | SCT multi-position tie-rod cylinder |
| Bore size | Ø32 mm |
| Stroke 1 / Stroke 2 | 110 / 110 mm |
| Total travel | 220 mm |
| Stop positions | 3 positions |
| Acting type | Double acting (tandem, multi-position) |
| Port size | PT1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 21 mm |
| Max stroke / section | Up to 500 mm standard |
Specifications follow the official AirTAC SCT (multi-position) datasheet. SCT is available in bores 32–100; each of the two sections has a 500 mm max standard stroke (800 mm max). Confirm against the product label before installation. Thread options: PT (standard) / G.
Stop Positions (3)
| Position | Rod extension |
|---|---|
| P0 (retracted) | 0 mm |
| P1 (section 1) | 110 mm |
| P2 (both extended) | 220 mm |
Positions are set by pressurising section 1, section 2, or both. With equal strokes you get 3 distinct positions; with unequal strokes you get 4.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
Force is per actuated piston section (single-piston, same as the SC bore): push uses the full bore area, pull subtracts the rod area. Size with a safety margin.
Model Code: Airtac SCT32-63 Multi-Position Tandem Air Cylinder SCT32X110X110
| SCT | Multi-position (tandem) tie-rod cylinder series. |
|---|---|
| 32 | Bore size in mm (SCT range 32–100). |
| ×110 | Stroke 1 (section 1) in mm. |
| ×110 | Stroke 2 (section 2) in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related types: SC (single rod), SCD (double rod), SCJ (adjustable stroke). SCT mounting: Basic, FA, FB, CA, CB, LB. Seals: TPU standard / H = Viton / N = NBR. Thread: blank = PT, G = G thread.
Where the Airtac SCT32-63 Multi-Position Tandem Air Cylinder SCT32X110X110 Is Used
3-Position Sorting Gate
Directs packages to three different conveyor lanes using the 0, 110, and 220 mm stops, eliminating the need for complex multi-actuator setups.
Two-Stage Clamping
Applies a light contact force at 110 mm before a full clamp at 220 mm, useful in assembly fixtures where parts must be held gently then secured.
Multi-Stop Feeding
Pushes components to two distinct positions along a track, reducing the number of actuators required for a sequential feeding operation.
Is the Airtac SCT32-63 Multi-Position Tandem Air Cylinder SCT32X110X110 the Right Cylinder?
Choosing the SCT32X110X110 over two separate cylinders simplifies plumbing and control for three-position moves. If your application needs more thrust, stepping up to the 40 mm bore provides 628 N of push per section at the same pressure. For replacement, match the bore, both 110 mm strokes, PT ports, and basic mounting. When ordering a direct substitute, ensure the magnet option matches your sensor setup.
Multi-position checklist
- ✓ Need 3 repeatable stops?
- ✓ Section strokes 110 + 110 mm suit your layout?
- ✓ Required force at your working pressure
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Plumb the two sections to the correct valves for each stop.
- check Adjust end cushion screws for smooth stops.
- check Use SCT mounting accessory (FA / FB / CA / CB / LB).
- check Installation by qualified personnel per AirTAC docs.
Airtac SCT32-63 Multi-Position Tandem Air Cylinder SCT32X110X110 FAQ
It provides three discrete rod positions: 0 mm (retracted), 110 mm (first section extended), and 220 mm (both sections extended).
Each of the two piston sections delivers 402 N of push force and 345 N of pull force when operated at 0.5 MPa.
