The AirTAC SEJ Adjustable Cylinder SEJ32X100-10 is a genuine double-acting ISO 15552 double-rod cylinder with a mechanically ADJUSTABLE stroke: a back-rod stop screw lets you fine-tune the retract end over a 10mm window, so this Ø32mm unit covers an effective stroke of 90–100mm without changing cylinders. Force is equal in both directions.
The AirTAC SEJ32X100-10 is a double-acting, double-rod ISO 15552 profile cylinder featuring a 10mm adjustable stroke window. A rod exits both ends, yielding equal annulus areas and an identical push and pull force of 345 N at 0.5 MPa. You can mechanically dial the retract end-position anywhere in an effective 90-100 mm range via a back-rod stop screw.
This 32 mm bore unit uses a PT1/8 port and a Ø12 mm rod end with an M10x1.25 thread. It includes field-adjustable air cushions at both ends to decelerate the load near stroke extremes. Because this SKU lacks a magnet, it does not support position sensing without external hardware.
| Model | Airtac SEJ Adjustable Cylinder SEJ32X100-10 |
|---|---|
| Series | SEJ ISO 15552 adjustable-stroke cylinder |
| Bore size | Ø32 mm |
| Nominal stroke | 100 mm |
| Adjustment window | 10 mm (90–100 mm) |
| Configuration | Double rod, double acting |
| Port size | PT1/8 |
| Rod thread | M10×1.25 |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
Specifications follow the official AirTAC SEJ datasheet and ISO 15552 / VDMA 24562 dimensions. The adjustment screw shortens the retract end only; do not exceed the 10mm window. Port options: PT (standard) / G (BSPP).
| Pressure | Force (both directions) |
|---|---|
| 0.5 MPa | 346 N |
| 0.7 MPa | 484 N |
| Max (@1.0 MPa) | 70 kgf |
A rod exits both ends, so extend and retract force are identical. Actual usable force is lower than theoretical; size with a safety margin.
| SEJ | ISO 15552 double-rod double-acting cylinder with adjustable stroke. |
|---|---|
| 32 | Bore size in mm. |
| ×100 | Nominal stroke length in mm. |
| -10 | Adjustment stroke window in mm (options: 10/20/30/40/50/75/100). |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting (SEJ): Basic, LB, FA, TC, FTC, TCM1, TCM2. Related: SED (double rod, fixed stroke), SE (single rod).
Dial in the exact 90-100 mm retract distance when placing delicate electronic components, using the 345 N both-way force without overtravel.
Quickly shift the mechanical stop to match different carton heights on a packaging line, avoiding pneumatic pressure changes.
Set precise compression distances on material test jigs where the 10 mm window allows incremental sample testing adjustments.
Verify the 10 mm adjustment window covers your required end-position variance. If you need less force, the smaller 32 mm bore is the entry point here, but stepping up to the next size, the 40 mm bore, raises the both-way force to 528 N at 0.5 MPa. If your stroke length is fixed and never changes, a standard SED double-rod cylinder provides the same output without the adjustment hardware.
For a direct ISO 15552 replacement, match the 32 mm bore, 100 mm nominal stroke, PT1/8 port, and your mounting choice from the SEJ subset (Basic, FA, LB, TC, FTC, TCM1, TCM2). Note that the air cushion and mechanical stop screw only set the end position and decelerate the load; they do not hold position on air loss. For fail-safe holding, use an external rod lock.
Quick checklist
The SEJ32X100-10 has a 10 mm adjustment window on the retract end, meaning the effective stroke can be dialed down from 100 mm to 90 mm. You set the exact end position via the back-rod stop screw and lock it in place.
Because the rod exits both ends, the force is equal in both directions: 345 N at 0.5 MPa and 483 N at 0.7 MPa. The maximum force is 70 kgf at 1.0 MPa.
