AirTAC SEJ Series · ISO 15552 Adjustable-Stroke Cylinder

Airtac SEJ Adjustable Cylinder SEJ32X100-100S

The AirTAC SEJ Adjustable Cylinder SEJ32X100-100S is a genuine double-acting ISO 15552 double-rod cylinder with a mechanically ADJUSTABLE stroke: a back-rod stop screw lets you fine-tune the retract end over a 100mm window, so this Ø32mm unit covers an effective stroke of 0–100mm without changing cylinders. Force is equal in both directions.

  • BoreØ32 mm
  • Nominal stroke100 mm
  • Adjust window100 mm
  • Effective stroke0–100 mm
  • Port sizePT1/8
  • CushionAdjustable, 27 mm
$70.01 $77.51Save 9% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SEJ32 stroke, mounting and version on one page All SEJ32 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SEJ Adjustable Cylinder SEJ32X100-100S

The AirTAC SEJ32X100-100S is a double-acting, double-rod ISO 15552 profile cylinder with a 100 mm mechanical stroke adjustment window. A stop screw on the rear rod lets you dial the retract end from 0 to 100 mm, providing exact end-position tuning directly on the machine without swapping hardware. Because a rod exits both ends, the annular area is identical in both directions, yielding an equal force of 345 N each way at 0.5 MPa.

This 32 mm bore unit features a Ø12 mm rod, M10x1.25 end threads, and PT1/8 ports. The extruded aluminum barrel contains no external tie rods, ensuring clean ISO 15552 dimensional interchangeability. Equipped with a standard magnet (-S), it supports CMSE reed and DMSE electronic sensors for position feedback. Field-adjustable air cushions at both ends manage deceleration near stroke limits.

Airtac SEJ Adjustable Cylinder SEJ32X100-100S Technical Specifications

ModelAirtac SEJ Adjustable Cylinder SEJ32X100-100S
SeriesSEJ ISO 15552 adjustable-stroke cylinder
Bore sizeØ32 mm
Nominal stroke100 mm
Adjustment window100 mm (0–100 mm)
ConfigurationDouble rod, double acting
Port sizePT1/8
Rod threadM10×1.25
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 27 mm

Specifications follow the official AirTAC SEJ datasheet and ISO 15552 / VDMA 24562 dimensions. The adjustment screw shortens the retract end only; do not exceed the 100mm window. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø32mm)

PressureForce (both directions)
0.5 MPa346 N
0.7 MPa484 N
Max (@1.0 MPa)70 kgf

A rod exits both ends, so extend and retract force are identical. Actual usable force is lower than theoretical; size with a safety margin.

Model Code: Airtac SEJ Adjustable Cylinder SEJ32X100-100S

SEJISO 15552 double-rod double-acting cylinder with adjustable stroke.
32Bore size in mm.
×100Nominal stroke length in mm.
-100Adjustment stroke window in mm (options: 10/20/30/40/50/75/100).
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting (SEJ): Basic, LB, FA, TC, FTC, TCM1, TCM2. Related: SED (double rod, fixed stroke), SE (single rod).

Where the Airtac SEJ Adjustable Cylinder SEJ32X100-100S Is Used

tune

Dispenser Probe Calibration

Dial the 0-100 mm retract window to set a precise probe height for varying bottle openings, using the 345 N equal both-way force to press consistently without rotating the assembly.

swap_horiz

Changeover Stop Adjustment

Switch a packaging line between different carton sizes by mechanically adjusting the stroke end-point on the fly, relying on the double-rod design for symmetrical speed.

precision_manufacturing

Light-Press Positioning

Fine-tune the seating depth of small electronic connectors during commissioning, leveraging the 483 N retract force at 0.7 MPa and locking the rear stop screw once the ideal depth is found.

Is the Airtac SEJ Adjustable Cylinder SEJ32X100-100S the Right Cylinder?

Confirm the 100 mm adjustment window covers your required positioning range. If you need less fine-tune travel, a shorter window or a fixed-stroke SED saves cost. For higher force, stepping up to the 40 mm bore provides 528 N both ways at 0.5 MPa; stepping down is not an option as 32 mm is the smallest in this series. If your application requires fail-safe position holding on air loss, note that this cylinder does not lock—specify a BSED or an external rod lock. For this 100 mm stroke, the built-in guides generally handle side loads, but always support external loads to maximize seal life.

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Adjustment window (100mm) covers your range
  • ✓ Equal force both directions OK
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Set the stop screw within the 100mm window; lock it after adjusting.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SEJ Adjustable Cylinder SEJ32X100-100S FAQ

A stop screw on the extending rear rod lets you mechanically shorten the retract stroke by up to 100 mm. This means your effective stroke range is 0 to 100 mm. You set the exact end-position during commissioning and lock the screw in place.

Because it is a double-rod cylinder, the force is identical in both extend and retract directions. It generates 345 N at 0.5 MPa, 483 N at 0.7 MPa, and a maximum of 70 kgf at 1.0 MPa.
