The AirTAC SEJ Adjustable Cylinder SEJ32X100-10S is a genuine double-acting ISO 15552 double-rod cylinder with a mechanically ADJUSTABLE stroke: a back-rod stop screw lets you fine-tune the retract end over a 10mm window, so this Ø32mm unit covers an effective stroke of 90–100mm without changing cylinders. Force is equal in both directions.
The AirTAC SEJ32X100-10S is a double-acting, double-rod ISO 15552 profile cylinder featuring a 10mm adjustable stroke window, yielding an effective stroke range of 90 to 100mm. A rod exits both ends, ensuring the annulus area is identical in both directions. This provides equal force and speed for pushing and pulling, delivering 345 N each way at 0.5 MPa.
The retract end is mechanically adjustable via a stop screw on the back rod, allowing you to dial in the exact end position during machine commissioning without changing hardware. The extruded aluminum barrel is dimensionally interchangeable per ISO 15552, omitting external tie rods. Equipped with a magnet, it supports CMSE reed and DMSE electronic sensors for position detection.
| Model | Airtac SEJ Adjustable Cylinder SEJ32X100-10S |
|---|---|
| Series | SEJ ISO 15552 adjustable-stroke cylinder |
| Bore size | Ø32 mm |
| Nominal stroke | 100 mm |
| Adjustment window | 10 mm (90–100 mm) |
| Configuration | Double rod, double acting |
| Port size | PT1/8 |
| Rod thread | M10×1.25 |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
Specifications follow the official AirTAC SEJ datasheet and ISO 15552 / VDMA 24562 dimensions. The adjustment screw shortens the retract end only; do not exceed the 10mm window. Port options: PT (standard) / G (BSPP).
| Pressure | Force (both directions) |
|---|---|
| 0.5 MPa | 346 N |
| 0.7 MPa | 484 N |
| Max (@1.0 MPa) | 70 kgf |
A rod exits both ends, so extend and retract force are identical. Actual usable force is lower than theoretical; size with a safety margin.
| SEJ | ISO 15552 double-rod double-acting cylinder with adjustable stroke. |
|---|---|
| 32 | Bore size in mm. |
| ×100 | Nominal stroke length in mm. |
| -10 | Adjustment stroke window in mm (options: 10/20/30/40/50/75/100). |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting (SEJ): Basic, LB, FA, TC, FTC, TCM1, TCM2. Related: SED (double rod, fixed stroke), SE (single rod).
Dial in the exact 90 to 100mm retraction distance on an electronics pick-and-place head to match varying PCB thicknesses, utilizing the 345 N both-way force for consistent component placement.
Fine-tune the sealing jaw position on a form-fill-seal machine during commissioning, using the 10mm stop screw window to match carton heights precisely without swapping hardware.
Confirm this 10mm adjustment window covers your required end-position range. If you need less force, there is no smaller standard SEJ bore, so a 32mm is the floor. If your application requires more push or pull, stepping up to the 40mm bore yields 528 N each way at 0.5 MPa. If your end position is fixed and never needs mechanical tuning, a standard SED double-rod cylinder provides sufficient functionality. The field-adjustable air cushions at both ends decelerate the load near the stroke ends but do not lock the position; for fail-safe holding on air loss, use an external rod lock. When replacing an ISO 15552 cylinder, verify the 32mm bore, 100mm nominal stroke, PT1/8 port, and mounting style (Basic, FA, LB, TC, FTC, TCM1, or TCM2).
Quick checklist
The retract end features a stop screw on the back rod that allows you to shorten the nominal 100mm stroke by up to 10mm. This provides an effective stroke range of 90 to 100mm, which is ideal for fine-tuning the exact end position on the machine during commissioning.
Because the rod exits both ends, the force is equal in both directions. It generates 345 N at 0.5 MPa, 483 N at 0.7 MPa, and a maximum of 70 kgf at 1.0 MPa.
